| # | Part Number | Description | Qty | Status |
|---|
| 1 |
852421T5 |
HOUSING Driveshaft [1C046581] & Below
|
1 |
superseded
|
| 1 |
852421T5 |
HOUSING Driveshaft [0P502069] & Below
|
1 |
superseded
|
| 1 |
852421T07 |
HOUSING Driveshaft - Long [1C046582] & Up
|
1 |
disc.
|
| 1 |
852421T07 |
HOUSING Driveshaft - Long [0P502070] & Up
|
1 |
disc.
|
| 10 |
856774 |
WASHER (.406 x .750 x .105) Stainless Steel
|
1 |
superseded
|
| 11 |
40140 |
NUT (M10)
|
1 |
|
| 12 |
888591001 |
TUBE Water
|
1 |
superseded
|
| 13 |
828529 |
GUIDE
|
1 |
|
| 14 |
828706 |
BUMPER
|
1 |
superseded
|
| 15 |
42941001 |
SEAL Water Tube
|
1 |
|
| 16 |
893770 |
PLATE Driveshaft Housing
|
1 |
disc.
|
| 17 |
1993325 |
SCREW (M10 x 25 MM)
|
1 |
|
| 18 |
892286 |
CAP
|
1 |
|
| 19 |
816311T |
TIE STRAP (8.00 Inches)
|
1 |
|
| 2 |
825220T06 |
PIPE Exhaust
|
1 |
|
| 20 |
13035002 |
FITTING
|
1 |
superseded
|
| 21 |
813745 |
SPACER
|
1 |
|
| 22 |
43585 |
COUPLING
|
1 |
|
| 23 |
855623 |
BUSHING
|
1 |
|
| 24 |
45176 |
WASHER (.453 x .812 x .105) Stainless Steel
|
2 |
|
| 25 |
40140 |
NUT (M10)
|
2 |
|
| 26 |
856774 |
WASHER (.406 x .750 x .105) Stainless Steel
|
4 |
superseded
|
| 27 |
4000380 |
SCREW (M10 x 45)
|
4 |
|
| 3 |
824459110 |
SCREW (M8 x 110) Stainless Steel
|
8 |
|
| 4 |
88960845 |
SCREW (M8 x 45)
|
5 |
|
| 5 |
8288181 |
PLUG Drain
|
1 |
|
| 6 |
828816 |
GASKET
|
1 |
superseded
|
| 7 |
826276 |
BUMPER
|
2 |
|
| 8 |
828817001 |
GROMMET
|
1 |
superseded
|
| 9 |
823984 |
STUD (M10 x 50) (Non-Bigfoot)
|
1 |
|
| 9 |
903501 |
STUD (M10 x 100) (Bigfoot-Long)
|
1 |
|
