| # | Part Number | Description | Qty | Status |
|---|
| 1 |
896963 |
NUT (M12)
|
2 |
|
| 10 |
893590T02 |
SWIVEL TUBE
|
1 |
superseded
|
| 11 |
88238A4 |
CABLE ASSEMBLY
|
1 |
superseded
|
| 12 |
88238A13 |
CABLE ASSEMBLY Ground
|
1 |
superseded
|
| 13 |
823567105 |
SCREW (M10 x 105) Hex Flange - Stainless Steel [1C046581] & Below
|
2 |
|
| 13 |
823567105 |
SCREW (M10 x 105) Hex Flange - Stainless Steel [0P502069] & Below
|
2 |
|
| 13 |
892086120 |
SCREW (M10 x 120) [1C046582] & Up
|
2 |
superseded
|
| 13 |
892086120 |
SCREW (M10 x 120) [0P502070] & Up
|
2 |
superseded
|
| 14 |
893703 |
STRAP Lower Mount
|
1 |
|
| 15 |
878607 |
SCREW (#10-16 x .375)
|
3 |
|
| 16 |
40140 |
NUT (M10)
|
2 |
|
| 17 |
19608A14 |
ATTACHING KIT Engine Steering (Non Handle)
|
1 |
|
| 18 |
823919 |
SCREW (.375-24 x 1.500) (Non Handle)
|
1 |
|
| 19 |
71970 |
WASHER (.390 x .546 x .12) (Non Handle)
|
1 |
superseded
|
| 2 |
893773002 |
STRAP Upper Mount
|
1 |
|
| 20 |
37828 |
WASHER (.390 x .625 x .062) Stainless Steel (Non Handle)
|
2 |
|
| 21 |
826709113 |
NUT (.375-24) Stainless Steel (Non Handle)
|
1 |
superseded
|
| 22 |
826709113 |
NUT (.375-24) Stainless Steel (Non Handle)
|
1 |
superseded
|
| 23 |
816667A2 |
BRACKET ASSEMBLY Steering Ride-Guide (Non Handle)
|
1 |
|
| 24 |
816669F1 |
TAB WASHER (Non Handle)
|
1 |
superseded
|
| 25 |
4000377 |
SCREW (M10 x 30) (Non Handle)
|
2 |
|
| 26 |
45176 |
WASHER (.453 x .812 x .105) Stainless Steel [1C046581] & Below
|
2 |
|
| 26 |
45176 |
WASHER (.453 x .812 x .105) Stainless Steel [0P502069] & Below
|
2 |
|
| 27 |
892086120 |
SCREW (M10 x 120) [1C046582] & Up
|
2 |
superseded
|
| 27 |
892086120 |
SCREW (M10 x 120) [0P502070] & Up
|
2 |
superseded
|
| 3 |
826267T2 |
MOUNT Upper
|
2 |
superseded
|
| 4 |
40011128 |
SCREW (M6 x 20) Stainless Steel
|
8 |
superseded
|
| 5 |
826658 |
BUMPER
|
1 |
superseded
|
| 6 |
89531 |
RING Retaining
|
1 |
|
| 7 |
825222F3 |
ARM Steering
|
1 |
superseded
|
| 8 |
42973 |
BOLT (M12 x 154)
|
2 |
superseded
|
| 9 |
8279971 |
SPACER
|
1 |
|
