| # | Part Number | Description | Qty | Status |
|---|
| - |
877829T03 |
MANIFOLD ASSEMBLY Intake - Complete [1B236230] & Below
|
1 |
superseded
|
| - |
877829T04 |
MANIFOLD ASSEMBLY Intake - Complete [1B236231] THRU [1B268340]
|
1 |
superseded
|
| - |
877829T05 |
MANIFOLD ASSEMBLY Intake - Complete [1B268341] & Up
|
1 |
superseded
|
| - |
883599A02 |
GASKET SET Powerhead
|
1 |
|
| 1 |
877829T |
MANIFOLD Intake [1B268340] & Below
|
1 |
superseded
|
| 1 |
877829T01 |
MANIFOLD Intake [1B268341] & Up
|
1 |
|
| 10 |
881059 |
SCREW
|
4 |
|
| 11 |
883460 |
CLIP
|
4 |
|
| 12 |
877831A1 |
HOSE
|
1 |
|
| 13 |
877831T |
THROTTLE BODY [1B268340] & Below
|
1 |
superseded
|
| 13 |
877831A02 |
THROTTLE BODY ASSEMBLY [1B268341] & Up
|
1 |
|
| 14 |
8M0000578 |
SCREW Adjustment [1B268341] & Up
|
1 |
|
| 15 |
881059 |
SCREW
|
2 |
|
| 16 |
881070T |
SENSOR Position
|
1 |
superseded
|
| 17 |
881060 |
SCREW
|
2 |
|
| 18 |
854445 |
SENSOR MAP
|
1 |
|
| 19 |
858535 |
SENSOR ASSEMBLY Temperature (Plastic)
|
1 |
superseded
|
| 19 |
885342001 |
SENSOR ASSEMBLY (Brass Housing)
|
1 |
superseded
|
| 2 |
879866 |
GASKET SET (Contains 4 Gaskets)
|
1 |
|
| 20 |
627021 |
O-RING (.301 x .070) (Use with Plastic Housing)
|
1 |
|
| 20 |
888814 |
O-RING (.351 x .072) (Use with Brass Housing)
|
1 |
superseded
|
| 21 |
879867 |
GASKET
|
1 |
|
| 22 |
881063T |
ATTENUATOR Sound [1B145285] & Below
|
1 |
superseded
|
| 22 |
881063T |
ATTENUATOR Sound [0P365416] & Below
|
1 |
superseded
|
| 22 |
893521 |
ATTENUATOR [1B145286] & Up
|
1 |
|
| 22 |
893521 |
ATTENUATOR [0P365417] & Up
|
1 |
|
| 23 |
8248326 |
SCREW (M6 x 25 MM)
|
8 |
|
| 24 |
8831483 |
RESTRICTOR (50)
|
1 |
|
| 24 |
8831482 |
RESTRICTOR (40)
|
1 |
|
| 25 |
880755A1 |
BREATHER HOSE
|
1 |
superseded
|
| 26 |
82684430 |
SCREW (M6 x 30)
|
1 |
|
| 27 |
816311T |
TIE STRAP (8.00 Inches)
|
3 |
|
| 28 |
8214281 |
SCREW (#10-16 x .625)
|
1 |
|
| 29 |
883832 |
RETAINER
|
1 |
superseded
|
| 3 |
881059 |
SCREW
|
1 |
|
| 4 |
877834 |
BRACKET
|
1 |
|
| 5 |
401366 |
NUT (M6) Stainless Steel
|
1 |
|
| 6 |
877805T |
SOLENOID VALVE
|
1 |
|
| 7 |
879887T |
TFI SYSTEM
|
1 |
|
| 8 |
877826 |
INJECTOR [USA-0T800999/BEL-0P267999] & Below
|
4 |
superseded
|
| 8 |
892123 |
INJECTOR [USA-0T801000] THRU [USA-0T979999]
|
4 |
superseded
|
| 8 |
892123 |
INJECTOR [BEL-0P268000] THRU [BEL-0P325499]
|
4 |
superseded
|
| 8 |
892123001 |
INJECTOR [USA-0T980000/BEL-0P325500] THRU [USA-1B236230]
|
4 |
superseded
|
| 8 |
892123002 |
INJECTOR [1B236231] & Up
|
4 |
|
| 9 |
881059 |
SCREW
|
2 |
|
