| # | Part Number | Description | Qty | Status |
|---|
| - |
883599A02 |
GASKET SET Powerhead
|
1 |
|
| 1 |
883214T1 |
COVER KIT
|
1 |
disc.
|
| 10 |
883215 |
TUBE Drain
|
1 |
|
| 11 |
9643 |
SCREW
|
5 |
|
| 12 |
883223 |
SCREW (M6 x 16)
|
6 |
|
| 13 |
883257T1 |
REGULATOR
|
1 |
|
| 14 |
883593A1 |
O-RING KIT
|
1 |
|
| 15 |
NSS |
NOT SOLD SEPARATE O Ring
|
1 |
|
| 16 |
883224A1 |
SEAL KIT
|
1 |
|
| 17 |
883216 |
GASKET
|
1 |
|
| 18 |
883221A1 |
FLOAT KIT
|
1 |
disc.
|
| 19 |
F10064 |
SHAFT
|
1 |
|
| 2 |
8554246 |
FITTING
|
2 |
disc.
|
| 20 |
883222A1 |
NEEDLE KIT Inlet
|
1 |
|
| 21 |
883546 |
BAFFLE Fuel
|
1 |
|
| 22 |
883226 |
HARNESS ASSEMBLY
|
1 |
superseded
|
| 23 |
883202T1 |
PUMP KIT [USA-0T979999/BEL-0P325499] & Below
|
1 |
superseded
|
| 23 |
883202T02 |
PUMP KIT [USA-0T980000/BEL-0P325500] & Up
|
1 |
|
| 24 |
855428 |
SLEEVE
|
1 |
superseded
|
| 25 |
883203 |
GROMMET
|
1 |
|
| 26 |
883211T1 |
BOWL KIT Fuel
|
1 |
disc.
|
| 27 |
883213 |
GASKET
|
1 |
|
| 28 |
883212001 |
SCREW Drain
|
1 |
disc.
|
| 29 |
8554241 |
FITTING
|
1 |
|
| 3 |
883210A1 |
PASS THRU KIT Electrical
|
1 |
|
| 30 |
883204T1 |
BODY KIT Fuel Cooler
|
1 |
disc.
|
| 31 |
889425 |
CLAMP
|
4 |
|
| 32 |
883205 |
FITTING
|
2 |
|
| 33 |
883208 |
PLUG
|
5 |
|
| 34 |
782792 |
FITTING Elbow 45 Degree (1.25)
|
2 |
superseded
|
| 35 |
883207 |
FITTING Elbow
|
1 |
disc.
|
| 36 |
883227 |
SCREW
|
1 |
disc.
|
| 37 |
883225 |
GASKET
|
1 |
disc.
|
| 38 |
883545 |
HOSE (4.50 Inches Bulk) (Cut to 1-5/8 Inches)
|
1 |
disc.
|
| 39 |
883545 |
HOSE (4.50 Inches Bulk) (Cut to 4-1/2 Inches)
|
1 |
disc.
|
| 4 |
883209 |
O-RING
|
1 |
superseded
|
| 40 |
8835451 |
HOSE
|
1 |
|
| 41 |
856954 |
BUSHING
|
3 |
|
| 42 |
834985 |
GROMMET
|
3 |
superseded
|
| 43 |
82130025 |
SCREW (M6 x 25)
|
3 |
|
| 44 |
4002316 |
WASHER (6.60 X 17.0 X 1.5SS)
|
3 |
superseded
|
| 5 |
NSS |
NOT SOLD SEPARATE Retainer
|
1 |
|
| 6 |
883205 |
FITTING
|
1 |
|
| 7 |
883218 |
FITTING
|
1 |
|
| 8 |
883219 |
VALVE
|
1 |
|
| 9 |
883220 |
CAP
|
1 |
|
