| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 881862T |
НАСОС Топливо [0T939654] & Below PUMP Fuel [0T939654] & Below |
1 | superseded |
| 1 | 881862T |
НАСОС Топливо [0P301503] & Below PUMP Fuel [0P301503] & Below |
1 | superseded |
| 1 | 881862T08 |
НАСОС Топливо [0T939655] THRU [1B050000] PUMP Fuel [0T939655] THRU [1B050000] |
1 | superseded |
| 1 | 881862T08 |
НАСОС Топливо [0P301504] THRU [0P340403] PUMP Fuel [0P301504] THRU [0P340403] |
1 | superseded |
| 1 | 892874T01 |
НАСОС В СБОРЕ Топливо (Sold Complete Only) [1B050001] & Up PUMP ASSEMBLY Fuel (Sold Complete Only) [1B050001] & Up |
1 | superseded |
| 1 | 892874T01 |
НАСОС В СБОРЕ Топливо (Sold Complete Only) [0P340404] & Up PUMP ASSEMBLY Fuel (Sold Complete Only) [0P340404] & Up |
1 | superseded |
| 10 | 830757130 |
ТРУБОПРОВОД (0.312) (общая длина 70.00") (Cut to 34 Inches) [0T939654] & Below TUBING (.312) (70.00 Inches Bulk) (Cut to 34 Inches) [0T939654] & Below |
1 | superseded |
| 10 | 830757130 |
ТРУБОПРОВОД (0.312) (общая длина 70.00") (Cut to 34 Inches) [0P301503] & Below TUBING (.312) (70.00 Inches Bulk) (Cut to 34 Inches) [0P301503] & Below |
1 | superseded |
| 10 | 830757130 |
ТРУБОПРОВОД (0.312) (общая длина 70.00") (Cut to 37 Inches) [0T939655] & Up TUBING (.312) (70.00 Inches Bulk) (Cut to 37 Inches) [0T939655] & Up |
1 | superseded |
| 10 | 830757130 |
ТРУБОПРОВОД (0.312) (общая длина 70.00") (Cut to 37 Inches) [0P301504] & Up TUBING (.312) (70.00 Inches Bulk) (Cut to 37 Inches) [0P301504] & Up |
1 | superseded |
| 11 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut to 19 Inches) [0T939654] & Below HOSE (57.00 Inches Bulk) (Cut to 19 Inches) [0T939654] & Below |
1 | superseded |
| 11 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut to 19 Inches) [0P301503] & Below HOSE (57.00 Inches Bulk) (Cut to 19 Inches) [0P301503] & Below |
1 | superseded |
| 11 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut to 16-1/2 Inches) [0T939655] & Up HOSE (57.00 Inches Bulk) (Cut to 16-1/2 Inches) [0T939655] & Up |
1 | superseded |
| 11 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut to 16-1/2 Inches) [0P301504] & Up HOSE (57.00 Inches Bulk) (Cut to 16-1/2 Inches) [0P301504] & Up |
1 | superseded |
| 12 | 830757130 |
ТРУБОПРОВОД (0.312) (общая длина 70.00") (Cut to 6 Inches) TUBING (.312) (70.00 Inches Bulk) (Cut to 6 Inches) |
1 | superseded |
| 13 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
AR | |
| 14 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut to 8 Inches) HOSE (57.00 Inches Bulk) (Cut to 8 Inches) |
1 | superseded |
| 15 | 879884T |
ФИЛЬТР В СБОРЕ Топливо FILTER ASSEMBLY Fuel |
1 | |
| 16 | 8M0149607 |
КОМПЛЕКТ ТОПЛИВНОГО ФИЛЬТРА FUEL FILTER KIT |
1 | superseded |
| 17 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut to 36 Inches) HOSE (57.00 Inches Bulk) (Cut to 36 Inches) |
1 | superseded |
| 18 | 816856A4 |
СОЕДИНИТЕЛЬ В СБОРЕ Топливо CONNECTOR ASSEMBLY Fuel |
1 | superseded |
| 19 | 856954 |
ВТУЛКА BUSHING |
1 | |
| 2 | 883517 |
ВИНТ [1B050000] & Below SCREW [1B050000] & Below |
4 | disc. |
| 2 | 883517 |
ВИНТ [0P340403] & Below SCREW [0P340403] & Below |
4 | disc. |
| 20 | 834985 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
1 | superseded |
| 21 | 4002316 |
ШАЙБА (6.60 X 17.0 X 1.5, нерж. сталь) WASHER (6.60 X 17.0 X 1.5SS) |
1 | superseded |
| 22 | 401196 |
ГАЙКА (M6) NUT (M6) |
1 | |
| 23 | 880121 |
КРОНШТЕЙН BRACKET |
1 | superseded |
| 24 | 40011126 |
ВИНТ (M6 x 13), нержавеющая сталь SCREW (M6 x 13) Stainless Steel |
2 | |
| 25 | 828547T1 |
КАБЕЛЕПРОВОД (Внутренний диаметр 0.500 x общая длина 3.00 фт.) (Cut to 13 Inches) CONDUIT (.500 Inside Diameter x 3.00 Feet Bulk) (Cut to 13 Inches) |
1 | |
| 26 | 828547T1 |
КАБЕЛЕПРОВОД (Внутренний диаметр 0.500 x общая длина 3.00 фт.) (Cut to 26 Inches) CONDUIT (.500 Inside Diameter x 3.00 Feet Bulk) (Cut to 26 Inches) |
1 | |
| 3 | 883520A1 |
КОМПЛЕКТ ДИАФРАГМ [1B050000] & Below DIAPHRAGM KIT [1B050000] & Below |
1 | disc. |
| 3 | 883520A1 |
КОМПЛЕКТ ДИАФРАГМ [0P340403] & Below DIAPHRAGM KIT [0P340403] & Below |
1 | disc. |
| 4 | 8835181 |
ПРУЖИНА [1B050000] & Below SPRING [1B050000] & Below |
1 | disc. |
| 4 | 8835181 |
ПРУЖИНА [0P340403] & Below SPRING [0P340403] & Below |
1 | disc. |
| 5 | 883519 |
ГАЙКА [1B050000] & Below NUT [1B050000] & Below |
4 | disc. |
| 5 | 883519 |
ГАЙКА [0P340403] & Below NUT [0P340403] & Below |
4 | disc. |
| 6 | 883518A2 |
ПРУЖИНА [0T939654] & Below SPRING [0T939654] & Below |
1 | superseded |
| 6 | 883518A2 |
ПРУЖИНА [0P301503] & Below SPRING [0P301503] & Below |
1 | superseded |
| 6 | 883518A03 |
ПРУЖИНА [0T939655] THRU [1B050000] SPRING [0T939655] THRU [1B050000] |
1 | |
| 6 | 883518A03 |
ПРУЖИНА [0P301504] THRU [0P340403] SPRING [0P301504] THRU [0P340403] |
1 | |
| 7 | NSS |
НЕ ПРОДАЕТСЯ ОТДЕЛЬНО Cap NOT SOLD SEPARATE Cap |
1 | |
| 8 | 8566031 |
ОТРАЖАТЕЛЬ Кожух DEFLECTOR Cowl |
1 | superseded |
| 9 | 82684430 |
ВИНТ (M6 x 30) SCREW (M6 x 30) |
2 |
