| # | Part Number | Description | Qty | Status |
|---|
| 1 |
822866T04 |
BRACKET Transom - Port (PORT)
|
1 |
|
| 1 |
822868A1 |
CLAMP BRACKET ASSEMBLY (PORT - THUMBSCREW)
|
1 |
superseded
|
| 10 |
99615 |
PIN Groove
|
1 |
|
| 11 |
19619 |
WASHER
|
2 |
|
| 12 |
18486A08 |
BRACKET KIT Anchor
|
1 |
|
| 13 |
818298Q1 |
ANODE KIT
|
1 |
|
| 14 |
4000330 |
SCREW (M6 x 25)
|
2 |
superseded
|
| 15 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
2 |
superseded
|
| 16 |
4000354 |
SCREW (M8 x 30)
|
5 |
|
| 17 |
4000355 |
SCREW (M8 x 35)
|
1 |
|
| 18 |
400257 |
LOCKWASHER (M8)
|
4 |
|
| 19 |
401388 |
NUT (M8) Stainless Steel
|
2 |
|
| 2 |
98727 |
FITTING Grease
|
1 |
superseded
|
| 20 |
8M0026068 |
PIN ASSEMBLY Tilt Lock (NON POWER TRIM)
|
1 |
|
| 21 |
821461 |
SPRING (NON POWER TRIM)
|
1 |
|
| 22 |
8M0041938 |
TILT TUBE
|
1 |
|
| 23 |
858869 |
NUT (.875-14)
|
2 |
|
| 24 |
814259 |
SCREW (.500-20 x 4.00)
|
4 |
|
| 25 |
28421 |
WASHER (1.5 x 3.05 x 0.13) Stainless Steel
|
4 |
superseded
|
| 26 |
82671117 |
NUT (.500-20)
|
4 |
|
| 27 |
8M0084737 |
LINK (NON POWER TRIM)
|
1 |
|
| 28 |
19615A05 |
LEVER ASSEMBLY Tilt (NON POWER TRIM)
|
1 |
|
| 29 |
812707 |
BUSHING (NON POWER TRIM)
|
1 |
|
| 3 |
99604 |
PIN Groove
|
1 |
|
| 30 |
8M0042643 |
WASHER (.520 x .850 x .060) Nylon, Black (NON POWER TRIM)
|
1 |
|
| 31 |
99611 |
WAVE WASHER (NON POWER TRIM)
|
1 |
|
| 32 |
8M0007469 |
KNOB Tilt (NON POWER TRIM)
|
1 |
|
| 33 |
19611 |
SCREW (.375-16 x .62) (NON POWER TRIM)
|
1 |
|
| 34 |
4009040 |
SCREW (M10 x 40) Stainless Steel
|
2 |
|
| 35 |
4002319 |
WASHER
|
2 |
|
| 36 |
40140 |
NUT (M10)
|
2 |
|
| 37 |
830253 |
DECAL Tilt Lock
|
1 |
|
| 38 |
19624A1 |
SEAL KIT (NON-HANDLE)
|
1 |
|
| 39 |
29619 |
O-RING (.583 x .103) (NON-HANDLE)
|
1 |
|
| 4 |
822865T05 |
BRACKET Transom - Starboard (STARBOARD)
|
1 |
|
| 4 |
822867F1 |
CLAMP BRACKET (STBD- THUMBSCREW
|
1 |
|
| 40 |
78861 |
SPACER (NON-HANDLE)
|
1 |
|
| 41 |
22740 |
CLIP (POWER TRIM)
|
2 |
|
| 42 |
8M0084613 |
C-WASHER (POWER TRIM)
|
1 |
|
| 43 |
878609 |
SCREW (#10-16 x .600) (POWER TRIM)
|
1 |
|
| 44 |
818883A1 |
THUMB SCREW ASSEMBLY (MANUAL BIGFOOT)
|
1 |
|
| 45 |
818884 |
WASHER (MANUAL BIGFOOT)
|
1 |
|
| 46 |
768042 |
SHOULDER SCREW Hex (MANUAL BIGFOOT)
|
1 |
|
| 47 |
NSS |
NOT SOLD SEPARATE Handle (MANUAL BIGFOOT)
|
1 |
|
| 48 |
NSS |
NOT SOLD SEPARATE Rivet (MANUAL BIGFOOT)
|
1 |
|
| 49 |
NSS |
NOT SOLD SEPARATE Decal-Warning (MANUAL BIGFOOT)
|
1 |
|
| 5 |
893704T01 |
LEVER Tilt Lock
|
1 |
|
| 6 |
99622 |
SPRING
|
1 |
|
| 7 |
65830 |
NYLINER
|
1 |
|
| 8 |
812708 |
SPRING
|
1 |
|
| 9 |
812709 |
KNOB
|
1 |
|
