| # | Part Number | Description | Qty | Status |
|---|
| 1 |
850066A1 |
SWIVEL BRACKET
|
1 |
superseded
|
| 10 |
8M0042636 |
NUT (.375-24) Brass
|
1 |
superseded
|
| 11 |
823792 |
LEVER Co-Pilot
|
1 |
|
| 12 |
29330 |
WASHER
|
1 |
|
| 13 |
821961 |
ROD Co-Pilot - Threaded
|
1 |
|
| 14 |
8M0006845 |
PLATE/DISC ASSEMBLY Brake
|
1 |
|
| 15 |
8M0007471 |
PLATE Swivel Head
|
1 |
|
| 16 |
8165621 |
DISC Friction
|
1 |
|
| 17 |
768042 |
SHOULDER SCREW Hex
|
2 |
|
| 2 |
19606 |
BEARING Trim Pin
|
2 |
|
| 3 |
74036 |
FITTING Grease
|
3 |
superseded
|
| 4 |
8237011 |
DECAL Co-Pilot
|
1 |
|
| 5 |
NSS |
NOT SOLD SEPARATE Decal-Serial Overlaminate
|
1 |
|
| 6 |
821777 |
BUSHING Lower
|
1 |
|
| 7 |
822404 |
SEAL Lower
|
1 |
superseded
|
| 8 |
4008910 |
SCREW (M8 x 10) Stainless Steel
|
1 |
|
| 9 |
8217711 |
BUSHING Upper
|
1 |
|
