| # | Part Number | Description | Qty | Status |
|---|
| - |
851886A98 |
POWERHEAD ASSEMBLY (Lightning)
|
1 |
superseded
|
| - |
802806A99 |
POWERHEAD ASSEMBLY (Lightning XR/50)
|
1 |
superseded
|
| - |
812937A98 |
GASKET SET Powerhead [0N016161] & Below
|
1 |
superseded
|
| - |
812937A02 |
GASKET SET Powerhead [0N016162] & Up
|
1 |
superseded
|
| 1 |
9614A2 |
CRANKSHAFT ASSEMBLY
|
1 |
superseded
|
| 10 |
16054A5 |
RING SET Piston (Standard)
|
3 |
disc.
|
| 10 |
16055A5 |
RING SET Piston (.5 Oversize)
|
AR |
disc.
|
| 11 |
160561 |
PIN Piston
|
3 |
superseded
|
| 12 |
160571 |
CLIP
|
6 |
|
| 13 |
853712 |
THRUST RING
|
2 |
|
| 14 |
160531 |
KEY
|
1 |
|
| 15 |
855553 |
BEARING Main (Upper)
|
1 |
|
| 16 |
803879 |
SEAL Oil
|
1 |
|
| 17 |
855554 |
O-RING
|
1 |
superseded
|
| 18 |
8130483 |
BEARING Needle
|
3 |
|
| 2 |
160492 |
BEARING Ball
|
1 |
superseded
|
| 3 |
855552 |
GEAR Drive
|
1 |
|
| 4 |
853714 |
C CLIP
|
1 |
|
| 5 |
880810 |
PIN Piston
|
2 |
|
| 6 |
880855 |
CONNECTING ROD
|
2 |
|
| 7 |
880856 |
BEARING Needle
|
2 |
|
| 8 |
880857 |
WASHER
|
4 |
|
| 9 |
96152 |
PISTON (Standard)
|
3 |
superseded
|
| 9 |
879194 |
PISTON (.5 Oversize)
|
AR |
|
