| # | Part Number | Description | Qty | Status |
|---|
| 1 |
805597A1 |
BRACKET ASSEMBLY
|
2 |
|
| 10 |
35048 |
LOCKWASHER (.375)
|
4 |
|
| 11 |
37269 |
SCREW (.437-14 x 2.00)
|
2 |
|
| 12 |
32993 |
LOCKWASHER (.437)
|
2 |
|
| 13 |
29553 |
NUT (.437-14)
|
2 |
disc.
|
| 14 |
8066985 |
TRUNNION
|
4 |
|
| 15 |
68102 |
LOCKWASHER (.750)
|
4 |
|
| 16 |
66284A2 |
BASE ASSEMBLY Engine End
|
2 |
|
| 17 |
20739 |
NUT (.750-16) Jam
|
2 |
|
| 18 |
66658 |
TAB WASHER
|
2 |
|
| 19 |
816326A2 |
BASE ASSEMBLY Transmission End
|
2 |
|
| 2 |
37269 |
SCREW (.437-14 x 2.00)
|
2 |
|
| 2 |
91903 |
SCREW (.437-14 x 1.750)
|
4 |
|
| 20 |
8M0022149 |
STUD (750-16)
|
2 |
|
| 21 |
47656 |
MOUNT
|
4 |
|
| 22 |
48611 |
WASHER
|
4 |
|
| 23 |
816331 |
NUT (.750-16) Jam
|
2 |
|
| 24 |
66658 |
TAB WASHER
|
2 |
|
| 25 |
20739 |
NUT (.750-16) Jam
|
2 |
|
| 26 |
78945 |
J CLAMP Harness Support
|
1 |
|
| 3 |
32993 |
LOCKWASHER (.437)
|
4 |
|
| 4 |
57357 |
SCREW (.437-13 x 2.250)
|
2 |
|
| 5 |
32993 |
LOCKWASHER (.437)
|
2 |
|
| 6 |
29553 |
NUT (.437-14)
|
2 |
disc.
|
| 7 |
71128A2 |
BRACKET
|
2 |
|
| 8 |
68101 |
SCREW (.375-16 x 1.375)
|
4 |
|
| 9 |
8M2004610 |
STUD (3/16-16 x 2.25)
|
2 |
|
