| # | Part Number | Description | Qty | Status |
|---|
| 1 |
865735A02 |
MANIFOLD ASSEMBLY Exhaust
|
2 |
superseded
|
| 10 |
863129 |
BALL
|
1 |
|
| 11 |
862994T |
FITTING
|
1 |
|
| 12 |
864850A02 |
GASKET Elbow, Restrictor
|
2 |
|
| 13 |
864309T02 |
ELBOW ASSEMBLY Exhaust Inline
|
2 |
|
| 13 |
864591T02 |
ELBOW ASSEMBLY Exhaust V-Drive
|
2 |
|
| 14 |
864689 |
PLUG Expansion
|
3 |
|
| 15 |
73379 |
PLUG (.250-18)
|
1 |
superseded
|
| 16 |
428611 |
FITTING Pipe - Brass (.750-14)
|
2 |
superseded
|
| 17 |
864623A1 |
FITTING ASSEMBLY With Tapped Fitting Port
|
1 |
|
| 17 |
866725 |
FITTING Straight (.750-14) With Out Tapped Fitting Starboard
|
1 |
|
| 18 |
865982045 |
SCREW (.375-16 x 6.00) Inline
|
8 |
|
| 18 |
864665 |
SCREW (.375-16 x 7.50) V-Drive
|
8 |
|
| 19 |
16604 |
FITTING Straight (.125-27) Barb
|
1 |
|
| 2 |
428611 |
FITTING Pipe - Brass (.750-14)
|
4 |
superseded
|
| 20 |
815504272 |
CLAMP Worm Gear Inline
|
8 |
|
| 21 |
44348001 |
TUBE Exhaust Inline
|
2 |
superseded
|
| 22 |
807153T |
PIPE Inline
|
2 |
|
| 3 |
390721 |
PLUG Pipe (.125-27) Brass
|
2 |
|
| 4 |
864689 |
PLUG Expansion
|
3 |
|
| 5 |
33395 |
GASKET
|
2 |
|
| 6 |
8M2000229 |
SCREW (.375-16 x 4.75)
|
8 |
superseded
|
| 7 |
12524 |
PLUG (.375-18 x .475) Brass
|
1 |
|
| 8 |
863786A1 |
FITTING ASSEMBLY Drain
|
2 |
|
| 9 |
864701 |
O-RING (1.112 x .103)
|
1 |
|
