| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0047215 |
MODULE KIT Fuel Pump, Complete With Drain Port
|
1 |
|
| 10 |
892681 |
REGULATOR
|
1 |
|
| 11 |
866170A01 |
PUMP ASSEMBLY Fuel - Low Pressure
|
1 |
|
| 12 |
NSS |
NOT SOLD SEPARATE Seal
|
1 |
|
| 13 |
NSS |
NOT SOLD SEPARATE Seal
|
1 |
|
| 14 |
NSS |
NOT SOLD SEPARATE Isolator, Lift Pump
|
1 |
|
| 15 |
866169T01 |
PUMP ASSEMBLY Fuel
|
1 |
|
| 16 |
NSS |
NOT SOLD SEPARATE Isolator
|
1 |
|
| 17 |
8M2018790 |
FILTER Pump Suction
|
1 |
|
| 18 |
8M2018792 |
CLIP
|
1 |
|
| 19 |
NSS |
NOT SOLD SEPARATE Seal
|
1 |
|
| 2 |
8M2010476 |
FITTING (3/8-18)
|
2 |
|
| 20 |
8M0056175 |
HARNESS ASSEMBLY
|
1 |
|
| 21 |
NSS |
NOT SOLD SEPARATE Retainer
|
1 |
|
| 22 |
NSS |
NOT SOLD SEPARATE Screw
|
1 |
|
| 23 |
892665 |
FILTER Fuel
|
1 |
superseded
|
| 24 |
892687A02 |
CARTRIDGE ASSEMBLY Fuel Filter
|
1 |
|
| 25 |
NSS |
NOT SOLD SEPARATE Cap, Fuel Filter Cartridge
|
1 |
|
| 26 |
NSS |
NOT SOLD SEPARATE Screw
|
3 |
|
| 27 |
NSS |
NOT SOLD SEPARATE Seal
|
1 |
|
| 28 |
8M0093688 |
FILTER Fuel
|
1 |
|
| 29 |
NSS |
NOT SOLD SEPARATE Seal
|
1 |
|
| 3 |
806608A02 |
PLUG ASSEMBLY (.500-13) Blue Housing With Drain Port Only
|
1 |
superseded
|
| 30 |
NSS |
NOT SOLD SEPARATE Cup, Fuel Filter Cartridge
|
1 |
|
| 31 |
88517 |
FITTING Reducing
|
1 |
|
| 32 |
892683 |
SEAL
|
1 |
|
| 33 |
866114 |
SCREW (.250-28) Special
|
1 |
|
| 4 |
892684 |
SCREW
|
8 |
|
| 5 |
892670A01 |
CHECK VALVE KIT
|
1 |
|
| 6 |
NSS |
NOT SOLD SEPARATE Check Valve
|
1 |
|
| 7 |
NSS |
NOT SOLD SEPARATE Plug
|
1 |
|
| 8 |
NSS |
NOT SOLD SEPARATE Seal
|
1 |
|
| 9 |
8M0086387 |
COVER Fuel Module Housing
|
1 |
disc.
|
| NS |
8M0047216 |
HOUSING Fuel Module Lower
|
1 |
|
