| # | Part Number | Description | Qty | Status |
|---|
| - |
897148A09 |
LONG BLOCK ASSEMBLY 75/80/90/100
|
1 |
superseded
|
| - |
897148A08 |
LONG BLOCK ASSEMBLY 115
|
1 |
|
| 1 |
8348084 |
STRAINER
|
1 |
|
| 10 |
816311T |
TIE STRAP (8.00 Inches)
|
1 |
|
| 11 |
859251 |
GROMMET
|
1 |
superseded
|
| 12 |
888523001 |
CLIP
|
1 |
|
| 13 |
8M0000915 |
HOSE Filter to Fuel Supply Module [1B419126] & Below
|
1 |
superseded
|
| 13 |
8M0012213 |
HOSE Filter to Fuel Supply Module [1B419127] THRU [1B794598]
|
1 |
superseded
|
| 13 |
8M0043799 |
HOSE Filter to Fuel Supply Module [1B794599] & Up
|
1 |
superseded
|
| 14 |
8M0000914 |
HOSE Fuel Inlet [1B794598] & Below
|
1 |
superseded
|
| 14 |
8M0043798 |
HOSE Fuel Inlet [1B794599] & Up
|
1 |
disc.
|
| 15 |
NSS |
NOT SOLD SEPARATE Cap
|
1 |
|
| 16 |
814634 |
CLAMP
|
3 |
|
| 17 |
8M0007865 |
TUBE Nylon
|
1 |
|
| 18 |
816311T |
TIE STRAP (8.00 Inches)
|
2 |
|
| 19 |
888988028 |
CLAMP (16.2 mm)
|
1 |
superseded
|
| 2 |
897775 |
HOSE Block Strainer to Fuel Supply Module [1B759587] & Below
|
1 |
superseded
|
| 2 |
8M0040122 |
HOSE Block Strainer to Fuel Supply Module [1B759588] & Up
|
1 |
|
| 3 |
897795A01 |
HOSE ASSEMBLY Fuel Supply Module Outlet
|
1 |
|
| 4 |
897649001 |
HOSE Fuel Supply Module to High Pressure Fuel Filter [1B418732] & Below
|
1 |
superseded
|
| 4 |
8M0012211 |
HOSE Fuel Supply Module to High Pressure Fuel Filter [1B418733] THRU [1B794598]
|
1 |
superseded
|
| 4 |
8M0043800 |
HOSE Fuel Supply Module to High Pressure Fuel Filter [1B794599] & Up
|
1 |
superseded
|
| 5 |
879885T |
FILTER Fuel
|
2 |
superseded
|
| 6 |
8M0008617 |
HOSE Filter to Rail [1B794598] & Below
|
1 |
superseded
|
| 6 |
8M0043801 |
HOSE Filter to Rail [1B794599] & Up
|
1 |
superseded
|
| 7 |
830756109 |
HOSE (57.00 Inches Bulk) Cut to 8.25 Inches
|
1 |
superseded
|
| 8 |
897654002 |
HOSE Fuel Supply Module to Vent Cannister [1B418767] & Below
|
1 |
superseded
|
| 8 |
8M0012212 |
HOSE Fuel Supply Module to Vent Cannister [1B418768] & Up
|
1 |
superseded
|
| 9 |
888988015 |
CLAMP (15.7 mm)
|
3 |
superseded
|
