| # | Part Number | Description | Qty | Status |
|---|
| 1 |
879345T77 |
STARTER MOTOR ASSEMBLY Complete
|
1 |
|
| 10 |
8M0047039 |
SPACER
|
4 |
|
| 11 |
8M0047038 |
MOUNT
|
8 |
superseded
|
| 12 |
88552645 |
SCREW (M8X45)
|
4 |
|
| 13 |
814634 |
CLAMP
|
1 |
|
| 14 |
43430 |
WASHER
|
4 |
|
| 15 |
8M0037204 |
SCREW Nylon, Push-In (.25-20 x .50)
|
2 |
|
| 16 |
8M0040205 |
CLAMP
|
2 |
|
| 2 |
898890T01 |
CABLE ASSEMBLY
|
1 |
|
| 3 |
400255 |
LOCKWASHER (M5)
|
1 |
|
| 4 |
400211 |
NUT (M5) Stainless Steel
|
1 |
|
| 5 |
400213 |
NUT (M8) Stainless Steel
|
1 |
|
| 6 |
26993 |
LOCKWASHER (.312)
|
1 |
superseded
|
| 7 |
93388A1 |
CABLE ASSEMBLY (6.00 Inches) Black
|
1 |
|
| 7 |
93388A8 |
CABLE ASSEMBLY (12.5 Inchs) Black
|
1 |
|
| 8 |
400255 |
LOCKWASHER (M5)
|
1 |
|
| 9 |
69034 |
SCREW AND LOCKWASHER (.312-18 x 1.00)
|
1 |
superseded
|
