| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 883599A02 |
КОМПЛЕКТ ПРОКЛАДОК GASKET SET Powerhead |
1 | |
| 1 | 8M0118182 |
ПЕРЕХОДНАЯ ПЛАСТИНА В СБОРЕ ADAPTER PLATE ASSEMBLY |
1 | |
| 10 | 4007455 |
ВИНТ (M6 x 55) SCREW (M6 x 55) |
1 | |
| 11 | 8M0213113 |
GASKET Adaptor Plate GASKET Adaptor Plate |
1 | |
| 12 | 845746 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING |
1 | |
| 13 | 8M0204741 |
SCREW (M6 x 1.0 x 20) Hex Wash HD SCREW (M6 x 1.0 x 20) Hex Wash HD |
3 | |
| 14 | 893765 |
ПЛАСТИНА Верхний маслозаборник PLATE Top Oil Pickup |
1 | |
| 15 | 855228 |
ЗАЖИМ CLAMP |
2 | |
| 16 | 854793 |
РУКАВ Маслозаборник HOSE Oil Pickup |
1 | |
| 17 | 893700 |
ОТРАЖАТЕЛЬНЫЙ ЩИТОК Маслозаборник BAFFLE Oil Pick-up |
1 | |
| 18 | 8M0210772 |
OIL PRESSURE RELIEF OIL PRESSURE RELIEF |
1 | |
| 19 | 8M0021330 |
ПРОБКА (M18) PLUG (M18) |
1 | |
| 2 | 23784 |
ШТИФТ Штифт PIN Dowel |
4 | |
| 20 | 899145 |
ЗАЖИМ Ленточный хомут CLIP Tie Strap |
1 | |
| 21 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
AR | |
| 22 | 8M0108355 |
РУКАВ (Общая длина 57") Cut to 17 Inches HOSE (57 Inches Bulk) Cut to 17 Inches |
1 | |
| 23 | 291112 |
ФИТИНГ FITTING |
1 | |
| 3 | 8M0219158 |
DIPSTICK Oil DIPSTICK Oil |
1 | |
| 4 | 822464 |
ПРОБКА PLUG |
2 | |
| 5 | 19565002 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
1 | |
| 6 | 8M0181665 |
FITTING Elbow, 90 Degree FITTING Elbow, 90 Degree |
1 | |
| 7 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
3 | |
| 8 | 8M0205513 |
SEAL Oil SEAL Oil |
1 | |
| 9 | 859594 |
ВТУЛКА BUSHING |
1 |
