| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0171553 |
GEAR HOUSING ASSEMBLY Complete
|
1 |
|
| - |
43035A05 |
SEAL KIT Gear Housing
|
1 |
|
| - |
882813A3 |
GEAR KIT Forward And Pinion 28 Teeth
|
1 |
|
| - |
803496T2 |
BEARING/SEAL KIT
|
1 |
|
| - |
888805A00 |
REPAIR KIT Clutch And Cam Follower
|
1 |
|
| 1 |
8M0118594 |
GEAR HOUSING ASSEMBLY Basic
|
1 |
|
| 10 |
8M0063266 |
SHIM SET
|
1 |
|
| 11 |
30894A1 |
BEARING SET Cup And Cone
|
1 |
|
| 12 |
NSS |
NOT SOLD SEPARATE Cup
|
1 |
|
| 13 |
882813A3 |
GEAR KIT Forward And Pinion 28 Teeth
|
1 |
|
| 14 |
30895T |
BEARING Needle
|
1 |
|
| 15 |
856823 |
RING Retaining
|
1 |
|
| 16 |
888805T |
CLUTCH
|
1 |
|
| 17 |
8M0140444 |
SHAFT Propeller
|
1 |
|
| 18 |
30893 |
SPRING
|
1 |
|
| 19 |
889990T |
GEAR Reverse
|
1 |
|
| 2 |
8227731 |
INSERT Threaded
|
2 |
|
| 20 |
12596T2 |
CARRIER ASSEMBLY Bearing
|
1 |
superseded
|
| 21 |
861844 |
O-RING
|
1 |
superseded
|
| 22 |
30956T |
BEARING Needle
|
1 |
|
| 23 |
70080 |
SEAL Oil Inner
|
1 |
superseded
|
| 24 |
70081 |
SEAL Oil Outer
|
1 |
superseded
|
| 25 |
12578T |
BEARING Roller
|
1 |
|
| 26 |
12577 |
THRUST WASHER
|
1 |
|
| 27 |
12576 |
BEARING Thrust
|
1 |
|
| 28 |
8M0034456 |
STUD (M8 X 1.25 X 48)
|
2 |
|
| 29 |
855941 |
WASHER (.323 x .590 x .112) Stainless Steel
|
2 |
|
| 3 |
899070 |
FOLLOWER Cam
|
1 |
|
| 30 |
401378 |
NUT (M8)
|
2 |
|
| 31 |
NSS |
NOT SOLD SEPARATE Decal-Gearcase Pinion Identification
|
1 |
|
| 4 |
8M4504018 |
CAM SHIFT
|
1 |
|
| 5 |
888806 |
ROD Clutch Actuator
|
1 |
|
| 6 |
8M0084243 |
PIN Cross
|
1 |
|
| 7 |
8M0084245 |
PIN Spring Locator Spring Locator
|
1 |
|
| 8 |
79910 |
SPRING
|
1 |
|
| 9 |
78910 |
WASHER
|
1 |
|
