| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M2012039 |
РУКАВ Cooling Tube to Y-Fitting HOSE Cooling Tube to Y-Fitting |
1 | |
| 10 | 8623175 |
РУКАВ Cylinder Block Drain to Distribution Fitting Port Cut to 23 Inches, Starboard 17 Inches HOSE Cylinder Block Drain to Distribution Fitting Port Cut to 23 Inches, Starboard 17 Inches |
2 | superseded |
| 11 | 863490 |
РУКАВ Water Drain Accumulator to Distribution Fitting HOSE Water Drain Accumulator to Distribution Fitting |
1 | |
| 12 | 865394 |
РУКАВ HOSE |
1 | |
| 13 | 865337 |
РУКАВ Sea Pump to Water Orifice 3 Point Manual Drain HOSE Sea Pump to Water Orifice 3 Point Manual Drain |
1 | superseded |
| 13 | 865234 |
РУКАВ Sea Pump to Water Orifice Single Point Air Actuated Drain HOSE Sea Pump to Water Orifice Single Point Air Actuated Drain |
1 | |
| 14 | NA |
NOT AVAILABLE Orifice Meter (See Cool Fuel System -Bravo page for service part number) NOT AVAILABLE Orifice Meter (See Cool Fuel System -Bravo page for service part number) |
1 | |
| 15 | 865235 |
РУКАВ Water Orifice to Power Steering Cooler HOSE Water Orifice to Power Steering Cooler |
1 | superseded |
| 16 | 8M2007277 |
РУКАВ Y-Fitting to Cooler HOSE Y-Fitting to Cooler |
1 | |
| 17 | 863841T |
ТРУБА Вода Brass Compact Hydraulic Steering TUBE Water Brass Compact Hydraulic Steering |
1 | |
| 18 | 862225 |
ФИТИНГ Pushlock - Block Drian Hose FITTING Pushlock - Block Drian Hose |
4 | |
| 19 | 863465 |
РУКАВ Drain Accumulator to Tee Fitting HOSE Drain Accumulator to Tee Fitting |
1 | |
| 2 | 862993 |
ФИТИНГ Y, (2) 1-1/4" Ниппели шлангов / (1) 3/4" Ниппель шланга FITTING Y, (2) 1-1/4 In. Hose Barbs / (1) 3/4 In. Hose Barb |
1 | |
| 20 | 863464 |
ФИТИНГ Tee Bravo Only FITTING Tee Bravo Only |
1 | |
| 21 | 627021 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.301 x 0.070) O-RING (.301 x .070) |
2 | |
| 22 | 864560 |
РУКАВ Tee Fitting to Port Elbow Non Riser, 1.7 Inch and 3 Inch Riser HOSE Tee Fitting to Port Elbow Non Riser, 1.7 Inch and 3 Inch Riser |
1 | |
| 22 | 864965 |
РУКАВ Tee Fitting to Port Elbow 4.7 Inch and 6 Inch Riser HOSE Tee Fitting to Port Elbow 4.7 Inch and 6 Inch Riser |
1 | disc. |
| 23 | 864561 |
РУКАВ Tee Fitting to Starboard Elbow Non Riser, 1.7 Inch and 3 Inch Riser HOSE Tee Fitting to Starboard Elbow Non Riser, 1.7 Inch and 3 Inch Riser |
1 | |
| 23 | 864966 |
РУКАВ Tee Fitting to Starboard Elbow 4.7 Inch and 6 Inch Riser HOSE Tee Fitting to Starboard Elbow 4.7 Inch and 6 Inch Riser |
1 | |
| 24 | 815504212 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
2 | |
| 25 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) CLAMP Worm Gear (1.56 Diameter) |
AR | |
| 26 | 815504228 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
2 | |
| 27 | 8M2001490 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
1 | superseded |
| 28 | 815504232 |
ЗАЖИМ Червячная передача (диаметр 2.50) CLAMP Worm Gear (2.50 Diameter) |
AR | |
| 3 | 4285069 |
РУКАВ (Общая длина 44.00") Exhaust Manifold to Y Fitting Port, Cut to 17.00 Inches HOSE (44.00 Inches Bulk) Exhaust Manifold to Y Fitting Port, Cut to 17.00 Inches |
1 | superseded |
| 3 | 4285069 |
РУКАВ (Общая длина 44.00") Exhaust Manifold to Orifice Fitting Starboard, Cut to 3.5 Inches HOSE (44.00 Inches Bulk) Exhaust Manifold to Orifice Fitting Starboard, Cut to 3.5 Inches |
1 | superseded |
| 4 | 863456A1 |
ШЛАНГ В СБОРЕ Thermostat Housing to Circulating Pump HOSE ASSEMBLY Thermostat Housing to Circulating Pump |
1 | |
| 5 | 863458 |
РУКАВ Thermostat Housing to Port Manifold HOSE Thermostat Housing to Port Manifold |
1 | |
| 6 | 863459 |
РУКАВ Thermostat Housing to Starboard Manifold HOSE Thermostat Housing to Starboard Manifold |
1 | |
| 7 | 8M2007277 |
РУКАВ Cooler to Accumulator HOSE Cooler to Accumulator |
1 | |
| 8 | 862603 |
ФИТИНГ Male Quick Connector, Threaded - Engine Block FITTING Male Quick Connector, Threaded - Engine Block |
2 | superseded |
| 9 | 864989A01 |
ФИТИНГИ В СБОРЕ Lower Distribution FITTING ASSEMBLY Lower Distribution |
1 | superseded |
