| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M2017132 |
РУКАВ Water Drain to Heat Exchanger HOSE Water Drain to Heat Exchanger |
1 | |
| 10 | 8M2017130 |
РУКАВ Heat Exchanger to Poppet HOSE Heat Exchanger to Poppet |
1 | |
| 11 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) CLAMP Worm Gear (1.56 Diameter) |
AR | |
| 12 | 8M2012906 |
РУКАВ (Общая длина 45") (Cut to Fit) HOSE (45 Inches Bulk) (Cut to Fit) |
1 | superseded |
| 2 | 815504222 |
ЗАЖИМ Червячная передача (диаметр 1.98) CLAMP Worm Gear (1.98 DIameter) |
AR | superseded |
| 3 | 8M2017359 |
РУКАВ Power Steering Cooler to Oil Cooler HOSE Power Steering Cooler to Oil Cooler |
1 | |
| 4 | 8M2017497 |
РУКАВ To Oil Cooler HOSE To Oil Cooler |
1 | |
| 5 | 862993 |
ФИТИНГ Y, (2) 1-1/4" Ниппели шлангов / (1) 3/4" Ниппель шланга FITTING Y, (2) 1-1/4 In. Hose Barbs / (1) 3/4 In. Hose Barb |
1 | |
| 6 | 815504228 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
2 | |
| 7 | 4285069 |
РУКАВ (Общая длина 44.00") To Drain (Cut to 9.5 Inches) HOSE (44.00 Inches Bulk) To Drain (Cut to 9.5 Inches) |
1 | superseded |
| 8 | 8M2007278 |
РУКАВ To Drain Housing HOSE To Drain Housing |
1 | |
| 9 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) CLAMP Worm Gear (1.56 Diameter) |
AR |
