| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M0045256 |
ВПУСКНОЙ КОЛЛЕКТОР Впуск MANIFOLD ASSEMBLY Intake |
1 | |
| 10 | 8M0043145 |
КРОНШТЕЙН Wire Harness BRACKET Wire Harness |
2 | |
| 11 | 687271 |
ФИТИНГ (0.250-18), 90 градусов – латунь FITTING (.250-18) 90 Degree - Brass |
1 | |
| 12 | 8M0046566 |
ПРОБКА Service Point CAP Valve Service Point |
1 | |
| 13 | 8M0222138 |
INJECTOR KIT Fuel INJECTOR KIT Fuel |
8 | |
| 14 | 879150A09 |
КОМПЛЕКТ УПЛОТНЕНИЙ (Contains 4 Upper and 4 Lower Seals) SEAL KIT (Contains 4 Upper and 4 Lower Seals) |
2 | |
| 15 | 8M2001570 |
ЗАЖИМ CLIP |
1 | |
| 16 | 8M0098781 |
КОМПЛЕКТ РУКАВА Includes Clamp HOSE KIT Includes Clamp |
1 | |
| 17 | 8M0222140 |
FUEL RAIL Port FUEL RAIL Port |
1 | |
| 18 | 8M0222142 |
FUEL RAIL Starboard FUEL RAIL Starboard |
1 | |
| 19 | 8M0044726 |
КЛАПАН В СБОРЕ VALVE ASSEMBLY |
1 | |
| 2 | 805403A1 |
КОМПЛЕКТ ПРОКЛАДОК GASKET SET |
1 | |
| 20 | 805515 |
ПРОБКА Вентиль давления топлива – латунь CAP Shrader Valve - Brass |
1 | disc. |
| 21 | 8M0103805 |
ВИНТ (M6 x 16 ММ), нержавеющая сталь Fuel Rail to Intake Manifold SCREW (M6 x 16mm) Stainless Steel Fuel Rail to Intake Manifold |
6 | |
| 22 | 8M6002226 |
ЗАЖИМ CLAMP |
2 | |
| 3 | 8M0044310 |
УПЛОТНЕНИЕ Intake Manifold SEAL Intake Manifold |
4 | |
| 4 | 8M0099429 |
VALVE ASSEMBLY Crankcase Vent VALVE ASSEMBLY Crankcase Vent |
1 | |
| 5 | 811553 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
1 | |
| 6 | 848764 |
ЗАЖИМ (21 мм) CLAMP (21 mm) |
1 | |
| 7 | 8M0042521 |
РУКАВ PCV Valve to Plenum HOSE PCV Valve to Plenum |
1 | |
| 8 | 8M2017579 |
ВИНТ (0.375-16 x 5.25) Intake Manifold to Head SCREW (.375-16 x 5.25) Intake Manifold to Head |
4 | |
| 9 | 8M0046395 |
ВИНТ (0.375-16 x 1.75) SCREW (.375-16 x 1.75) |
12 |
