| # | Part Number | Description | Qty | Status |
|---|
| - |
9148A8 |
GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio COMPLETE
|
1 |
superseded
|
| - |
42579A4 |
REBUILD KIT Water Pump
|
1 |
superseded
|
| - |
89238A2 |
SEAL KIT
|
1 |
|
| - |
14697A87 |
GASKET SET
|
AR |
disc.
|
| 1 |
9148A11 |
GEAR HOUSING ASSEMBLY
|
1 |
superseded
|
| 11 |
44000 |
DRIVESHAFT
|
1 |
superseded
|
| 12 |
N.S.S. |
Not Sold Separate (PART OF 43-44104A2)
|
1 |
|
| 13 |
92721 |
WASHER (.965 x .630) PINION GEAR
|
1 |
|
| 14 |
35921 |
NUT (.625-18) PINION GEAR TO DRIVE SHAFT
|
1 |
|
| 15 |
42637A1 |
SHIM SET ROLLER BEARING TO GEAR HOUSING
|
AR |
disc.
|
| 16 |
36387A1 |
BEARING ASSEMBLY Roller/Cup DRIVE SHAFT
|
1 |
superseded
|
| 17 |
42633 |
NUT DRIVE SHAFT BEARING
|
1 |
superseded
|
| 18 |
42579A3 |
BASE ASSEMBLY Water Pump
|
1 |
superseded
|
| 19 |
42631 |
GASKET WATER PUMP TO GEAR HSG
|
1 |
superseded
|
| 2 |
85822A1 |
CONNECTOR ASSEMBLY SPEEDOMETER
|
1 |
superseded
|
| 20 |
90011 |
O-RING (2.175 x .175) WATER PUMP
|
1 |
superseded
|
| 21 |
89238 |
SEAL Oil WATER PUMP
|
1 |
|
| 22 |
16977 |
SEAL Oil WATER PUMP
|
1 |
|
| 23 |
856081 |
GASKET LOWER-WATER PUMP
|
1 |
superseded
|
| 24 |
856091 |
GASKET UPPER-WATER PUMP
|
1 |
superseded
|
| 25 |
32435 |
FACE PLATE FACE-WATER PUMP
|
1 |
superseded
|
| 26 |
96148A1 |
BODY ASSEMBLY Water Pump
|
1 |
superseded
|
| 27 |
48752 |
INSERT WATER PUMP BODY
|
1 |
superseded
|
| 28 |
38970 |
SEAL RUBBER-WATER INLET TUBE
|
1 |
|
| 29 |
89984 |
IMPELLER WATER PUMP
|
1 |
superseded
|
| 3 |
20033 |
PIN Dowel GEAR HOUSING LOCATING
|
2 |
superseded
|
| 30 |
56654 |
KEY IMPELLER DRIVE
|
1 |
superseded
|
| 31 |
96411 |
SCREW (#14-8 x 2.25) WATER PUMP (2-1/4")
|
1 |
superseded
|
| 32 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel WATER PUMP SCREW AND STUD
|
2 |
superseded
|
| 33 |
13438 |
NUT (.250-28) WATER PUMP STUD
|
2 |
superseded
|
| 34 |
36001 |
WASHER WATER PUMP STUD
|
1 |
|
| 35 |
13436 |
NUT WATER PUMP STUD
|
1 |
|
| 36 |
30271 |
RING Rubber RUBBER (DRIVE SHAFT)
|
1 |
superseded
|
| 37 |
29804 |
SLEEVE GUIDE-WATER INLET TUBE
|
1 |
superseded
|
| 38 |
78902 |
SHAFT SHIFT (LOWER)
|
1 |
superseded
|
| 39 |
29641 |
E RING RETAINING-SHIFT SHAFT
|
1 |
|
| 4 |
78638 |
STUD (.438 x 3.12) GEAR HOUSING (3-1/8")
|
1 |
superseded
|
| 40 |
78907 |
RING Retaining
|
1 |
disc.
|
| 41 |
25439 |
O-RING (.862 x .103) SHIFT SHAFT BUSHING
|
1 |
|
| 42 |
77631A2 |
BUSHING ASSEMBLY SHIFT SHAFT
|
1 |
|
| 43 |
76384 |
SEAL Oil SHIFT SHAFT BUSHING
|
1 |
superseded
|
| 44 |
77674 |
WASHER (.35 x .75 x .12) RUBBER-SHIFT SHAFT BUSHING
|
1 |
|
| 45 |
79953 |
SCREW (.375-16 x .250) GREASE FILLER
|
1 |
superseded
|
| 46 |
67892 |
SCREW Magnetic DRAIN ( MAGNETIC)
|
1 |
superseded
|
| 47 |
19183 |
WASHER Fiber GREASE FILLER AND DRAIN SCREW
|
2 |
superseded
|
| 5 |
57920 |
STUD (.44 x 2.06) GEAR HOUSING (2-1/16")
|
2 |
superseded
|
| 6 |
56297 |
STUD (.312 x 3.38) WATER PUMP (3-3/8")
|
1 |
superseded
|
| 7 |
30667 |
STUD (.250-20/.250-28 x 3.125) WATER PUMP (3-1/8")
|
2 |
superseded
|
| 8 |
42647A1 |
BEARING ASSEMBLY Roller DRIVE SHAFT
|
1 |
|
| 9 |
43998 |
SLEEVE LUBRICATION
|
1 |
disc.
|
