| # | Part Number | Description | Qty | Status |
|---|
| - |
14697A87 |
GASKET SET
|
1 |
disc.
|
| 1 |
904841 |
GASKET DIVIDER PLATE
|
2 |
|
| 10 |
813938 |
CAP NUT (#10-32) TERMINAL BLOCK
|
3 |
|
| 11 |
74824 |
SCREW (.312-18 x 1.250) COVER TO CYLINDER BLOCK (1-1/4")
|
4 |
|
| 12 |
69570 |
SCREW (#10-16 x .750) DIAPHRAGM TO PLATE (3/4")
|
1 |
|
| 13 |
76451 |
WASHER DIAPHRAGM SCREW
|
1 |
|
| 14 |
14479 |
DIAPHRAGM
|
1 |
superseded
|
| 15 |
16496 |
DEFLECTOR Water
|
1 |
|
| 16 |
16497A1 |
PLATE RELIEF VALVE
|
1 |
|
| 17 |
78690 |
GASKET RELIEF VALVE PLATE
|
2 |
superseded
|
| 18 |
64878 |
SPRING (Black) COMPERSSION POPPER VALVE
|
1 |
|
| 19 |
85303 |
WASHER POPPET SPRING
|
1 |
|
| 2 |
99169A1 |
PLATE DIVIDER
|
1 |
disc.
|
| 20 |
14480 |
POPPET VALVE
|
1 |
|
| 21 |
64872 |
GROMMET POPPET VALVE
|
1 |
|
| 22 |
65848 |
CARRIER POPPET VALVE
|
1 |
|
| 23 |
991763 |
GASKET EXHAUST PLATE
|
1 |
superseded
|
| 24 |
41944A5 |
PLATE ASSEMBLY EXHAUST
|
1 |
disc.
|
| 25 |
99664 |
ELBOW EXHAUST PLATE
|
1 |
superseded
|
| 26 |
20033 |
PIN Dowel LOCATING - EXHAUST PLATE
|
2 |
superseded
|
| 27 |
183982 |
SEAL EXHAUST PLATE
|
1 |
superseded
|
| 28 |
680101 |
BRACKET SEAL RETAINING
|
1 |
|
| 29 |
812832 |
SCREW (#10-16 x .500) BRACKET TO EXHAUST PLATE (1/2")
|
6 |
superseded
|
| 3 |
69668 |
SEAL DIVIDER PLATE
|
1 |
superseded
|
| 30 |
25970 |
WASHER POWERHEAD STUD
|
6 |
superseded
|
| 31 |
69254 |
NUT POWWERHEAD STUD
|
6 |
|
| 32 |
27132 |
BUSHING EXHAUST PLATE
|
1 |
|
| 33 |
19564 |
GROMMET
|
1 |
superseded
|
| 34 |
12602 |
GROMMET EXHAUST PLATE
|
1 |
superseded
|
| 35 |
66727 |
SCREW (.312-18 x 1.250) EXHAUST PLATE ATTACHING (1-1/4")
|
1 |
|
| 36 |
68783 |
SCREW (.312-18 x 2.50) EXHAUST PLATE ATTACHING (2-1/2")
|
1 |
|
| 37 |
66725 |
SCREW (.375-16 x 3.50) EXHAUST PLATE ATTACHING (3-1/2")
|
3 |
superseded
|
| 38 |
812905A2 |
BRACKET ASSEMBLY FRONT
|
1 |
superseded
|
| 39 |
90285 |
SCREW (.312-18 x .625) FRONT BRAKET
|
4 |
|
| 4 |
193071 |
COVER EXHAUST MANIFOLD
|
1 |
disc.
|
| 40 |
187031 |
WASHER
|
4 |
|
| 41 |
18778 |
GROMMET
|
4 |
superseded
|
| 42 |
18578A3 |
BRACKET ASSEMBLY Rear REAR
|
1 |
superseded
|
| 43 |
14462A1 |
COVER RELIEF VALVE (OLD DESIGN)
|
1 |
disc.
|
| 43 |
68729 |
COVER RELIEF VALVE (NEW DESIGN)
|
1 |
superseded
|
| 44 |
92007 |
FITTING (.250-18) (90 DEGREES) (NEW DESIGN)
|
1 |
superseded
|
| 45 |
99127109 |
LINE (57.00 Inches Bulk) (NEW DESIGN)
|
1 |
superseded
|
| 46 |
90077 |
TIE STRAP (NEW DESIGN)
|
2 |
superseded
|
| 47 |
814430 |
FITTING (.500-14) (NEW DESIGN)
|
1 |
superseded
|
| 5 |
74824 |
SCREW (.312-18 x 1.250) COVER AND PLATE TO CYLINDER BLOCK (1-1/4")
|
21 |
|
| 6 |
194373 |
TERMINAL BLOCK (3 TERMIALS)
|
1 |
disc.
|
| 7 |
13716 |
PARTS MANUAL 7.5 /9.8 H.P. TERMIAL BL0CK
|
2 |
|
| 8 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel TERMIMAL BLOCK SCREW
|
2 |
superseded
|
| 9 |
45076 |
NUT (#10-32) Brass TERMINAL BLOCK
|
3 |
|
