| # | Part Number | Description | Qty | Status |
|---|
| 1 |
74897 |
PIVOT TRIGGER PLATE
|
1 |
superseded
|
| 10 |
13627 |
SCREW (.190-32 x 1.250) SPARK ADVANCE LEVER - STOP (1-1/4")
|
1 |
disc.
|
| 11 |
68219 |
NUT (#10-32) Stainless Steel SPARK ADVANCE LEVER STOP SCREW
|
1 |
|
| 12 |
48039 |
CAP SPARK ADVANCE LEVER STOP SCREW
|
1 |
|
| 13 |
41095T |
LEVER THROTTLE CONTROL
|
1 |
superseded
|
| 14 |
55337 |
SCREW (.375-16 x 1.75) THROTTLE LEVER/ADVANCE LEVER (1-3/4")
|
1 |
superseded
|
| 15 |
55164 |
BUSHING THROTTLE LEVER
|
1 |
|
| 16 |
55171 |
BUSHING SPARK ADVANCE LEVER
|
1 |
disc.
|
| 17 |
68784 |
SPRING THROTTLE AND SPARK ADVANCE LEVER
|
1 |
|
| 18 |
68410 |
WASHER SPARK ADVANCE LEVER
|
1 |
disc.
|
| 19 |
64022 |
SCREW (.250-20 x 2.125) THROTTLE LEVER - STOP (2-1/8")
|
1 |
|
| 2 |
62459 |
BALL JOINT ASSEMBLY TRIGGER PLATE
|
1 |
superseded
|
| 20 |
64015 |
NUT (.250-20) THROTTLE LEVER STOP SCREW
|
1 |
|
| 21 |
26852 |
CAP Nylon THROTTLE LEVER STOP SCREW
|
1 |
|
| 22 |
39483 |
LATCH CABLE
|
1 |
|
| 23 |
22486 |
SCREW (.250-28 x .880) CABLE LATCH TO THROTTLE LEVER
|
1 |
superseded
|
| 24 |
20099 |
SPRING CABLE LATCH TO THROTTLE LEVER
|
1 |
|
| 25 |
20586 |
NUT (.250-28) CABLE LATCH SCREW
|
1 |
superseded
|
| 26 |
14634 |
ROD THROTTLE CONTROL
|
1 |
disc.
|
| 27 |
14638 |
BARREL THROTTLE CONTROL ROD
|
1 |
|
| 28 |
146351 |
CAM Throttle
|
1 |
disc.
|
| 29 |
93248 |
BUSHING
|
1 |
superseded
|
| 3 |
45076 |
NUT (#10-32) Brass LINK ROD
|
1 |
|
| 30 |
26856 |
BUSHING THROTTLE CAM
|
2 |
|
| 31 |
35045 |
NUT (.250-28) THROTTLE CAM STUD
|
1 |
superseded
|
| 32 |
41050 |
SPRING THROTTLE RETURN
|
1 |
disc.
|
| 33 |
92032A2 |
BRACKET ANCHOR - CTRL CABLES [C239552] & Below
|
1 |
superseded
|
| 33 |
814283A1 |
BRACKET ANCHOR - CONTROL CABLES [C239553] & Up
|
1 |
superseded
|
| 34 |
98889 |
LATCH CONTROL CABLE
|
1 |
|
| 35 |
42975 |
DRIVE SCREW LATCH
|
2 |
|
| 36 |
53167 |
SCREW (.312-18 x .880) ANCHOR BRACKET ATTACHING
|
3 |
superseded
|
| 37 |
37896 |
GUIDE BLOCK LINK ROD [C239552] & Below
|
1 |
disc.
|
| 37 |
814284 |
GUIDE BLOCK LINK ROD [C239553] & Up
|
1 |
|
| 38 |
20099 |
SPRING LINK ROD TO GUIDE BLOCK
|
1 |
|
| 39 |
67073A1 |
LINK ROD ASSEMBLY
|
1 |
|
| 4 |
76035 |
ROD TRIGGER PLATE
|
1 |
disc.
|
| 40 |
52100 |
WEAR PLATE LINK ROD
|
1 |
|
| 41 |
38279 |
LATCH CONTROL CABLE FASTENING ANCHOR BRACKET
|
1 |
superseded
|
| 42 |
35462 |
WASHER (.2656 x .625 x .0625) Stainless Steel LATCH
|
1 |
|
| 43 |
35045 |
NUT (.250-28) LINK ROD
|
1 |
superseded
|
| 44 |
79932A11 |
SHIFT SHAFT ASSEMBLY
|
1 |
superseded
|
| 45 |
29720 |
WAVE WASHER LINK ROD
|
1 |
|
| 46 |
26600 |
BUSHING NYLON - LINK ROD
|
1 |
disc.
|
| 47 |
35462 |
WASHER (.2656 x .625 x .0625) Stainless Steel LINK ROD
|
1 |
|
| 48 |
35045 |
NUT (.250-28) LINK ROD TO SHIFT SHAFT
|
1 |
superseded
|
| 49 |
39519 |
CUP BARRELL RETAINER - ANCHOR BAR
|
1 |
|
| 5 |
46438 |
NUT (#10-32) BALL JOINT
|
1 |
|
| 6 |
41094A3 |
LEVER ASSEMBLY SPARK ADVANCE
|
1 |
|
| 7 |
64022 |
SCREW (.250-20 x 2.125) SPARK ADVANCE LEVER - STOP
|
1 |
|
| 8 |
64015 |
NUT (.250-20) SPARK ADVANCE STOP SCREW
|
1 |
|
| 9 |
26852 |
CAP Nylon SPARK ADVANCE LEVER STOP SCREW
|
1 |
|
