| # | Part Number | Description | Qty | Status |
|---|
| - |
9148A30 |
GEAR HOUSING ASSEMBLY Counter Rotation (X-LONG) (BLACK)
|
1 |
superseded
|
| - |
9148A31 |
GEAR HOUSING ASSEMBLY Counter Rotation (X-LONG) (GRAY)
|
1 |
superseded
|
| - |
89238A2 |
SEAL KIT
|
1 |
|
| 1 |
9148A11 |
GEAR HOUSING ASSEMBLY (BASIC) (BLACK)
|
1 |
superseded
|
| 1 |
9148A12 |
GEAR HOUSING ASSEMBLY (BASIC) (GRAY)
|
1 |
superseded
|
| 47 |
78956 |
SHIFT CAM
|
1 |
superseded
|
| 48 |
89594A1 |
FOLLOWER ASSEMBLY CAM
|
1 |
|
| 49 |
79911 |
ROD CLUTCH ACTUATOR
|
1 |
superseded
|
| 50 |
79910 |
SPRING COMPRESSION
|
2 |
|
| 51 |
78910 |
WASHER SPRING
|
AR |
|
| 52 |
78906 |
PIN SPRING LOCATOR
|
1 |
superseded
|
| 53 |
14469 |
CUP Bearing
|
1 |
superseded
|
| 54 |
88957A1 |
BEARING Ball
|
1 |
superseded
|
| 55 |
N.S.S. |
Not Sold Separate Reverse Gear (PART OF 43-18475A1)
|
1 |
|
| 56 |
15844 |
BEARING ASSEMBLY Roller
|
1 |
|
| 57 |
78909 |
PIN Detent RATCHET
|
2 |
|
| 58 |
78959 |
RATCHET SLIDIING CLUTCH
|
1 |
superseded
|
| 59 |
78905 |
PIN Cross RATCHET
|
1 |
superseded
|
| 60 |
78962 |
SPRING RETAINING - CROSS PIN
|
2 |
|
| 61 |
18475A1 |
GEAR ASSEMBLY Forward
|
1 |
superseded
|
| 62 |
176151 |
SPACER SHIM (.125)
|
AR |
|
| 62 |
176152 |
SPACER SHIM (.127)
|
AR |
|
| 62 |
176153 |
SPACER SHIM (.129)
|
AR |
|
| 62 |
176154 |
SPACER SHIM (.131)
|
AR |
|
| 62 |
176155 |
SPACER SHIM (.133)
|
AR |
|
| 62 |
176156 |
SPACER SHIM (.135)
|
AR |
|
| 62 |
176157 |
SPACER SHIM (.137)
|
AR |
|
| 62 |
176158 |
SPACER SHIM (.139)
|
AR |
|
| 62 |
176159 |
SPACER SHIM (.141)
|
AR |
|
| 62 |
1761510 |
SPACER SHIM (.143)
|
AR |
|
| 62 |
1761511 |
SPACER SHIM (.145)
|
AR |
|
| 62 |
1761512 |
SPACER SHIM (.147)
|
AR |
|
| 62 |
1761513 |
SPACER SHIM (.149)
|
AR |
|
| 63 |
15841 |
BEARING Roller
|
1 |
|
| 64 |
17616 |
THRUST RING
|
1 |
|
| 65 |
31534 |
O-RING BEARING CARRIER
|
1 |
superseded
|
| 66 |
18447A2 |
ADAPTER ASSEMBLY Bearing
|
1 |
superseded
|
| 67 |
15843 |
BEARING Roller
|
1 |
superseded
|
| 68 |
18448 |
THRUST WASHER
|
2 |
|
| 69 |
15842 |
BEARING Thrust
|
2 |
|
| 70 |
18446 |
PROPELLER SHAFT
|
1 |
disc.
|
| 71 |
18444A1 |
CARRIER ASSEMBLY Bearing
|
1 |
superseded
|
| 72 |
30956 |
BEARING Needle BEARING CARRIER
|
2 |
superseded
|
| 73 |
76868 |
SEAL BEARING CARRIER
|
2 |
superseded
|
| 74 |
79447 |
TAB WASHER GEAR HOUSING COVER
|
1 |
|
| 75 |
79448 |
RETAINER GEAR HOUSING
|
1 |
superseded
|
| 76 |
30281 |
KEY LOCATING - BEARIING CARRIER
|
1 |
|
| 77 |
31640A1 |
TRIM TAB ASSEMBLY GEAR HOUSING
|
1 |
superseded
|
| 78 |
66024 |
SCREW (.437-14 x 1.75) TRIM TAB TO GEAR HOUSING
|
1 |
|
| 79 |
67891 |
FILLER BLOCK
|
1 |
superseded
|
| 80 |
45176 |
WASHER (.453 x .812 x .105) Stainless Steel DRIVESHAFT HOUSING STUDS
|
2 |
|
| 81 |
34933 |
NUT (.437-20) Stainless Steel DRIVESHAFT HOUSING STUDS
|
2 |
superseded
|
| 82 |
13171 |
THRUST HUB
|
1 |
superseded
|
| 83 |
31211A2 |
WASHER Splined PROPELLER NUT
|
1 |
superseded
|
| 84 |
31210 |
TAB WASHER PROPELLER NUT
|
1 |
superseded
|
| 85 |
52707A1 |
PROP NUT KIT (.750-16)
|
1 |
superseded
|
| 86 |
423511 |
LOCKWASHER Toothed PROPELLER SHAFT
|
1 |
|
| 87 |
74727 |
SCREW (.375-16 x 6.00) GEAR HOUSING
|
1 |
|
