| # | Part Number | Description | Qty | Status |
|---|
| - |
9148A8 |
GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (LONG)(BLACK)
|
1 |
superseded
|
| - |
9148A9 |
GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (X-LONG)(BLACK)
|
1 |
superseded
|
| - |
9148A10 |
GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (LONG)(GRAY)
|
1 |
superseded
|
| - |
9148A13 |
GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (X-LONG)(GRAY)
|
1 |
superseded
|
| - |
89238A2 |
SEAL KIT
|
1 |
|
| - |
89221A88 |
GASKET SET
|
1 |
disc.
|
| 1 |
9148A11 |
GEAR HOUSING ASSEMBLY (BASIC) (BLACK)
|
1 |
superseded
|
| 1 |
9148A12 |
GEAR HOUSING ASSEMBLY (BASIC) (GRAY)
|
1 |
superseded
|
| 48 |
78956 |
SHIFT CAM
|
1 |
superseded
|
| 49 |
89594A1 |
FOLLOWER ASSEMBLY CAM
|
1 |
|
| 50 |
79911 |
ROD CLUTCH ACTUATOR
|
1 |
superseded
|
| 51 |
79910 |
SPRING COPRESSION
|
2 |
|
| 52 |
78910 |
WASHER COMPRESSION SPRING
|
AR |
|
| 53 |
78906 |
PIN SPRING LOCATOR
|
1 |
superseded
|
| 54 |
47397A1 |
SHIM SET BEARING OUTER RACE (.001-3-5-10)
|
AR |
|
| 55 |
78172A1 |
BEARING ASSEMBLY Taper Roller
|
1 |
|
| 56 |
44104A2 |
GEAR ASSEMBLY Forward
|
1 |
superseded
|
| 57 |
43999 |
BEARING Roller (1.308 O.D.)
|
2 |
disc.
|
| 57 |
73363 |
BEARING Roller (1.313 O.D.)
|
2 |
superseded
|
| 58 |
78959 |
RATCHET SLIDING CLUTCH
|
1 |
superseded
|
| 59 |
78905 |
PIN Cross RATCHET TO PROPELLER SHAFT
|
1 |
superseded
|
| 60 |
78909 |
PIN Detent RATCHET
|
2 |
|
| 61 |
78962 |
SPRING RETAINING - CROSS PIN
|
2 |
|
| 62 |
94148 |
PROPELLER SHAFT
|
1 |
|
| 63 |
N.S.S. |
Not Sold Separate Reverse Gear (PART OF 43-44104A2)
|
1 |
|
| 64 |
68100 |
RING THRUST
|
1 |
superseded
|
| 65 |
88957A1 |
BEARING Ball REVERSE GEAR
|
1 |
superseded
|
| 66 |
31534 |
O-RING BEARING CARRIER
|
1 |
superseded
|
| 67 |
43567A1 |
CARRIER ASSEMBLY Bearing
|
1 |
superseded
|
| 68 |
30956 |
BEARING Needle BEARING CARRIER
|
1 |
superseded
|
| 69 |
76868 |
SEAL BEARING CARRIER
|
2 |
superseded
|
| 70 |
30281 |
KEY LOCATING - BEARING CARRIER
|
1 |
|
| 71 |
79447 |
TAB WASHER GEAR HOUSING COVER
|
1 |
|
| 72 |
79448 |
RETAINER GEAR HOUSING
|
1 |
superseded
|
| 73 |
31640A1 |
TRIM TAB ASSEMBLY GEAR HOUSING
|
1 |
superseded
|
| 74 |
66024 |
SCREW (.437-14 x 1.75) TRIM TAB TO GEAR HOUSING
|
1 |
|
| 75 |
67891 |
FILLER BLOCK
|
1 |
superseded
|
| 76 |
34933 |
NUT (.437-20) Stainless Steel DRIVESHAFT HOUSING STUDS
|
2 |
superseded
|
| 77 |
65210 |
SCREW (.375-16 x 1.00) GEAR HOUSING (LONG)
|
1 |
|
| 77 |
74727 |
SCREW (.375-16 x 6.00) GEAR HOUSING (X-LONG)
|
1 |
|
| 78 |
13171 |
THRUST HUB
|
1 |
superseded
|
| 79 |
31211A2 |
WASHER Splined PROPELLER NUT
|
1 |
superseded
|
| 80 |
31210 |
TAB WASHER PROPELLER NUT
|
1 |
superseded
|
| 81 |
52707A1 |
PROP NUT KIT (.750-16)
|
1 |
superseded
|
| 82 |
423511 |
LOCKWASHER Toothed PROPELLER SHAFT
|
1 |
|
| 83 |
45176 |
WASHER (.453 x .812 x .105) Stainless Steel DRIVESHAFT HOUSING STUDS
|
2 |
|
