CHOKE PLATE AND THROTTLE LEVERS (S/N-C239553 AND UP)
Parts (19)
| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 18866T |
КРЫШКА SOUND ATTENUATOR COVER SOUND ATTENUATOR |
1 | discontinued |
| 10 | 87604 |
СОЕДИНИТЕЛЬ Дроссельная заслонка LINK Throttle |
1 | discontinued |
| 11 | 93332A1 |
РЫЧАГ В СБОРЕ Дроссельная заслонка LEVER ASSEMBLY Throttle |
1 | superseded |
| 12 | 41048 |
РЫЧАГ Дроссельная заслонка LEVER Throttle |
1 | superseded |
| 13 | 67748 |
РОЛИК LOWER THROTTLE LEVER ROLLER LOWER THROTTLE LEVER |
1 | |
| 14 | 15124 |
ВИНТ (№10-32 x 0.750) THROTTLE LEVERS TO THROTTLE LINK SCREW (#10-32 x .750) THROTTLE LEVERS TO THROTTLE LINK |
3 | |
| 15 | 26996 |
СТОПОРНАЯ ШАЙБА (№10), нержавеющая сталь THROTTLE LEVERS SCREW LOCKWASHER (#10) Stainless Steel THROTTLE LEVERS SCREW |
3 | |
| 16 | 56681 |
ШАЙБА (0.203 x 0.500 x 0.032) THROTTLE LEVERS SCREW WASHER (.203 x .500 x .032) THROTTLE LEVERS SCREW |
3 | superseded |
| 17 | 67297 |
ШТИФТ Вилка THROTTLE LEVERS TO THROTTLE LINK PIN Clevis THROTTLE LEVERS TO THROTTLE LINK |
3 | |
| 18 | 89302 |
ШАЙБА (0.203 x 0.406 x 0.040) CLEVIS PIN WASHER (.203 x .406 x .040) CLEVIS PIN |
3 | |
| 19 | 26953 |
ШПЛИНТ CLEVIS PIN COTTER PIN CLEVIS PIN |
3 | |
| 2 | 92051 |
ВИНТ (10-16 x 0.75) SCREW (10-16 x .75) |
14 | |
| 3 | 188891 |
ПРОКЛАДКА SOUND ATTENUATOR GASKET SOUND ATTENUATOR |
1 | discontinued |
| 4 | 188672 |
ПЛАСТИНА Шумопоглотитель PLATE Sound Attenuator |
1 | superseded |
| 5 | 892211 |
ПРОКЛАДКА PLATE TO CARBURETOR GASKET PLATE TO CARBURETOR |
3 | |
| 6 | 68000 |
ВИНТ (0.250-28 x 1.00) SOUND ATTENUATOR SCREW (.250-28 x 1.00) SOUND ATTENUATOR |
6 | discontinued |
| 7 | 20583 |
ШАЙБА SOUND ATTENUATOR SCREW WASHER SOUND ATTENUATOR SCREW |
6 | |
| 8 | 64871A2 |
ОБРАТНЫЙ КЛАПАН CHECK VALVE |
1 | discontinued |
| 9 | 15026 |
ПРОБКА CAP |
1 |
