| # | Part Number | Description | Qty | Status |
|---|
| - |
11338A88 |
GASKET SET Engine Overhaul
|
1 |
disc.
|
| 1 |
8710A17 |
SWIVEL BRACKET ASSEMBLY (BLACK)
|
1 |
superseded
|
| 1 |
8710A18 |
SWIVEL BRACKET ASSEMBLY (GRAY)
|
1 |
superseded
|
| 10 |
77326 |
MOUNT RUBBER-UPPER
|
2 |
|
| 11 |
66921 |
WASHER UPPER MOUNT BOLT
|
2 |
|
| 12 |
78688 |
WASHER UPPER MOUNT BOLT
|
2 |
|
| 13 |
34933 |
NUT (.437-20) Stainless Steel UPPER MOUNT BOLT
|
2 |
superseded
|
| 14 |
92876A1 |
LINK ASSEMBLY Steering
|
1 |
superseded
|
| 15 |
14000 |
SCREW (.375-24 x 1.25) STEERING LINK TO STEERING ARM
|
1 |
superseded
|
| 16 |
34863 |
NUT (.375-24) STEERING LINK SCREW
|
2 |
superseded
|
| 17 |
34931 |
WASHER (.406 x .734 x .063) Stainless Steel STEERING LINK TO STEERING ARM
|
2 |
|
| 18 |
78854 |
WAVE WASHER BOTTOM YOKE
|
1 |
|
| 19 |
86580A1 |
YOKE ASSEMBLY Bottom (BLACK)
|
1 |
disc.
|
| 19 |
86580A2 |
YOKE ASSEMBLY Bottom (GRAY)
|
1 |
superseded
|
| 2 |
87735 |
SEAL Oil SWIVEL BRACKET (LOWER)
|
1 |
|
| 20 |
67684 |
RING Retaining BOTTOM YOKE
|
1 |
|
| 21 |
67670 |
WASHER THRUST-SWIVEL BRACKET
|
1 |
disc.
|
| 22 |
88882 |
BUMPER Top Yoke TOP YOKE
|
1 |
|
| 23 |
95164A9 |
SENDER ASSEMBLY Trim
|
1 |
superseded
|
| 24 |
56682 |
SCREW (#10-24 x .750) TRIM SENDER
|
2 |
superseded
|
| 25 |
26996 |
LOCKWASHER (#10) Stainless Steel TRIM SENDER SCREW
|
2 |
|
| 26 |
89302 |
WASHER (.203 x .406 x .040) TRIM SENDER SCREW
|
2 |
|
| 27 |
64014 |
SCREW (.250-28 x .500) SWIVEL BRACKET
|
2 |
|
| 28 |
54457 |
J CLIP
|
1 |
|
| 3 |
67669 |
BUSHING SWIVEL BRACKET (LOWER AND UPPER)
|
2 |
superseded
|
| 4 |
33466 |
O-RING SWIVEL BRACKET (UPPER)
|
1 |
|
| 5 |
67668 |
SPACER SWIVEL BRACKET (UPPER)
|
1 |
disc.
|
| 6 |
74036 |
FITTING Grease
|
2 |
superseded
|
| 7 |
99608 |
BUSHING SWIVEL BRACKET
|
2 |
superseded
|
| 8 |
67706A30 |
SWIVEL PIN ASSEMBLY Black (BLACK)
|
1 |
superseded
|
| 8 |
67706A31 |
SWIVEL PIN ASSEMBLY Gray (GRAY)
|
1 |
superseded
|
| 9 |
78689 |
SCREW (.437-20 x 7.50) STEERING ARM TO UPPER MOUNT
|
2 |
superseded
|
