| # | Part Number | Description | Qty | Status |
|---|
| 1 |
7620A27 |
TOP COWL ASSEMBLY PORT (BLACK)
|
1 |
disc.
|
| 1 |
7620A28 |
TOP COWL ASSEMBLY PORT (GRAY)
|
1 |
disc.
|
| 10 |
87987 |
BRACKET COWL ATTACHING (UPPER)
|
2 |
superseded
|
| 11 |
87985 |
BRACKET COWL ATTACHING (LOWER)
|
2 |
superseded
|
| 12 |
37562 |
SCREW (.312-18 x 1.00) Stainless Steel UPPER AND LOWER BRACKETS
|
8 |
|
| 13 |
68049 |
SHIELD INLET - COWL (STARBOARD)
|
1 |
disc.
|
| 13 |
68048 |
SHIELD INLET - COWL (PORT)
|
1 |
disc.
|
| 14 |
48409 |
SCREW (#10-16 x .625) Stainless Steel SHIELD TO COWL
|
4 |
|
| 15 |
62628 |
BARREL RETAINING - COWL LATCH
|
2 |
disc.
|
| 16 |
46785A5 |
LATCH ASSEMBLY Cowl
|
2 |
disc.
|
| 17 |
31312 |
SCREW (#10-32 x 0.875) BARRELL TO COWL LATCH
|
2 |
disc.
|
| 18 |
15222 |
BAR ADJUSTING - COWL LATCH
|
2 |
disc.
|
| 19 |
62629 |
BARREL RETAINING COWL LATCH
|
2 |
disc.
|
| 2 |
7619A6 |
TOP COWL ASSEMBLY STARBOARD (BLACK)
|
1 |
disc.
|
| 2 |
7619A7 |
TOP COWL ASSEMBLY STARBOARD (GRAY)
|
1 |
disc.
|
| 20 |
62624 |
SPRING COWL LATCH
|
2 |
disc.
|
| 21 |
30164 |
WASHER (.192 x .375 x .0312) Stainless Steel SPRING TO ADJUSTING BAR
|
2 |
|
| 22 |
45812 |
NUT (#10-32) Stainless Steel SPRING TO ADJUSTING BAR
|
2 |
superseded
|
| 23 |
7532A2 |
COVER ASSEMBLY Cowl - Front (BLACK)
|
1 |
disc.
|
| 23 |
7532A23 |
COVER ASSEMBLY Cowl - Front (GRAY)
|
1 |
disc.
|
| 24 |
67615 |
BLANKET SOUND - COWL FRONT COVER
|
1 |
disc.
|
| 25 |
87907 |
HOOK COWL FRONT COVER
|
1 |
disc.
|
| 26 |
70332 |
SCREW (#10-16 x .500) HOOK TO COWL FRONT COVER
|
1 |
superseded
|
| 27 |
47341A1 |
ROPE AND HANDLE KIT Manual/Emergency Start (FOR MANUAL STARTING)
|
1 |
superseded
|
| 28 |
16636A1 |
HARNESS ASSEMBLY
|
1 |
disc.
|
| 3 |
17196A1 |
SHIELD AIR INLET
|
2 |
disc.
|
| 30 |
72202 |
SCREW (#10-32 x 1.25) SWITCH
|
2 |
|
| 31 |
56681 |
WASHER (.203 x .500 x .032) SWITCH SCREW
|
2 |
superseded
|
| 32 |
34059 |
NUT (#10-32) SWITCH SCREW
|
2 |
superseded
|
| 33 |
16639A1 |
HARNESS ASSEMBLY
|
1 |
disc.
|
| 34 |
22875 |
CLIP HARNESS
|
1 |
|
| 35 |
48408 |
SCREW (#10-16 x .500) HARNESS CLIP
|
1 |
|
| 36 |
69205 |
C WASHER HARNESS CLIP
|
1 |
superseded
|
| 4 |
113161 |
NUT
|
12 |
superseded
|
| 5 |
17238 |
SEAL AIR INLET
|
4 |
disc.
|
| 6 |
17194 |
SHIELD AIR INLET (PORT)
|
1 |
disc.
|
| 6 |
17195 |
SHIELD AIR INLET (STARBOARD)
|
1 |
disc.
|
| 7 |
67260 |
SEAL CONTROL CABLE
|
2 |
disc.
|
| 8 |
88227 |
BLANKET SOUND - COWL
|
2 |
disc.
|
| 9 |
67258 |
PAD COWL ASSEMBLY TO FRONT COVER (PORT)
|
1 |
disc.
|
