| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 865324 |
БЫСТРОРАЗЪЕМНЫЙ QUICK CONNECT |
2 | |
| 10 | 865672079 |
РУКАВ (Общая длина 96.00") Design II (Cut to 13.5 Inches) 5.0/350/377 HOSE (96.00 Inches Bulk) Design II (Cut to 13.5 Inches) 5.0/350/377 |
1 | superseded |
| 10 | 865672079 |
РУКАВ (Общая длина 96.00") Design II (Cut to 9 Inches) 4.3 HOSE (96.00 Inches Bulk) Design II (Cut to 9 Inches) 4.3 |
1 | superseded |
| 11 | 1743534 |
РУКАВ (14.5") Design II HOSE (14.5 Inches) Design II |
1 | |
| 12 | 865672079 |
РУКАВ (Общая длина 96.00") Design II (Cut to Fit) HOSE (96.00 Inches Bulk) Design II (Cut to Fit) |
1 | superseded |
| 13 | 8M4501756 |
ФИТИНГ Design II Y-FITTING Design II |
1 | |
| 14 | 861427 |
ПРОБКА CAP |
1 | superseded |
| 15 | 861405 |
ФИТИНГ FITTING |
1 | superseded |
| 16 | 861406 |
ГНЕЗДО SOCKET |
1 | |
| 17 | 815504212 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
2 | |
| 18 | 86438765 |
РУКАВ (34") HOSE (34 Inches) |
1 | superseded |
| 2 | 865362 |
БЫСТРОРАЗЪЕМНЫЙ Design I QUICK CONNECT Design I |
1 | |
| 3 | 864727 |
ФИТИНГ Y, (3) 1-1/4" Н.Д. ниппелей шлангов (If Required) FITTING Y, (3) 1-1/4 In. OD Hose Barbs (If Required) |
1 | |
| 4 | 815504222 |
ЗАЖИМ Червячная передача (диаметр 1.98) CLAMP Worm Gear (1.98 DIameter) |
AR | superseded |
| 5 | 865672079 |
РУКАВ (Общая длина 96.00") Design I (Cut to 19 Inches) 5.0/350/377 HOSE (96.00 Inches Bulk) Design I (Cut to 19 Inches) 5.0/350/377 |
1 | superseded |
| 5 | 865672079 |
РУКАВ (Общая длина 96.00") Design I (Cut to 15 Inches) 4.3L HOSE (96.00 Inches Bulk) Design I (Cut to 15 Inches) 4.3L |
1 | superseded |
| 6 | 865672013 |
РУКАВ (4.00") Design I HOSE (4.00 Inches) Design I |
1 | superseded |
| 7 | 862993 |
ФИТИНГ Y, (2) 1-1/4" Ниппели шлангов / (1) 3/4" Ниппель шланга Design I FITTING Y, (2) 1-1/4 In. Hose Barbs / (1) 3/4 In. Hose Barb Design I |
1 | |
| 8 | 865672079 |
РУКАВ (Общая длина 96.00") Design I (Cut to Fit) HOSE (96.00 Inches Bulk) Design I (Cut to Fit) |
1 | superseded |
| 9 | 865470 |
КОРПУС Впуск HOUSING Inlet |
1 |
