| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 865674 |
РУКАВ Power Steering Cooler to Drain Fitting HOSE Power Steering Cooler to Drain Fitting |
1 | |
| 10 | NA |
NOT AVAILABLE Orifice Meter Assembly (See Cool Fuel System -Bravo page for service part number NOT AVAILABLE Orifice Meter Assembly (See Cool Fuel System -Bravo page for service part number |
1 | |
| 11 | 866729 |
ФИТИНГ (NPTF 0.250 x 0.250) FITTING (.250 x .250 NPTF) |
1 | |
| 12 | 861505 |
ФИТИНГ Drain Tee FITTING Drain Tee |
1 | |
| 13 | 863841T |
ТРУБА Вода Brass Compact Hydralic Steering TUBE Water Brass Compact Hydralic Steering |
1 | |
| 14 | 864435 |
РУКАВ Port Exhaust Elbow to Thermostat Housing HOSE Port Exhaust Elbow to Thermostat Housing |
1 | |
| 15 | 862210A01 |
КОМПЛЕКТ КОЛЕНЧАТОГО ПАТРУБКА Слив ELBOW KIT Drain |
2 | |
| 16 | 806608A02 |
УЗЕЛ ПРОБКИ (0.500-13), синий PLUG ASSEMBLY (.500-13) Blue |
9 | superseded |
| 17 | 8M2000926 |
УПЛОТНЕНИЕ SEAL |
9 | superseded |
| 18 | 860088 |
ВТУЛКА BUSHING |
4 | superseded |
| 19 | 46982 |
ФИТИНГ (90 градусов) FITTING (90 Degree) |
1 | |
| 2 | 865235 |
РУКАВ Water Orifice to Power Steering Cooler HOSE Water Orifice to Power Steering Cooler |
1 | superseded |
| 20 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) CLAMP Worm Gear (1.56 Diameter) |
4 | |
| 21 | 815504228 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
11 | |
| 22 | 8M2001490 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
4 | superseded |
| 3 | 865409 |
РУКАВ Drain Fitting to Thermostat Housing HOSE Drain Fitting to Thermostat Housing |
1 | |
| 4 | 866725 |
ФИТИНГ Прямой (0.750-14) Barb FITTING Straight (.750-14) Barb |
1 | |
| 5 | 864703A1 |
РУКАВ Circulating Pump to Drain Elbow HOSE Circulating Pump to Drain Elbow |
1 | |
| 6 | 864979 |
РУКАВ Starboard Exhaust Elbow to Thermostat Housing HOSE Starboard Exhaust Elbow to Thermostat Housing |
1 | |
| 7 | 863459 |
РУКАВ Thermostat Housing to Starboard Manifold HOSE Thermostat Housing to Starboard Manifold |
1 | |
| 8 | 863458 |
РУКАВ Thermostat Housing to Port Manifold HOSE Thermostat Housing to Port Manifold |
1 | |
| 9 | 865337 |
РУКАВ Sea Water Pump to Water Orifice HOSE Sea Water Pump to Water Orifice |
1 | superseded |
