| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 863661A2 |
ЛОНГ-БЛОК В СБОРЕ LONGBLOCK ASSEMBLY |
1 | disc. |
| 1 | 8503991 |
НАСОС В СБОРЕ Вода PUMP ASSEMBLY Water |
1 | superseded |
| 10 | 885192 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING |
1 | |
| 11 | 884018001 |
ВИНТ SCREW |
1 | |
| 12 | 807730T |
ШКИВ Crankshaft PULLEY Crankshaft |
1 | |
| 13 | 34352 |
ВИНТ (0.375-24 x 0.875) SCREW (.375-24 x .875) |
3 | |
| 14 | 863397 |
ВИБРОГАСИТЕЛЬ HARMONIC BALANCER |
1 | |
| 15 | 32515 |
ВИНТ (0.437-20 x 2.50) SCREW (.437-20 x 2.50) |
1 | superseded |
| 16 | 39131 |
СТОПОРНАЯ ШАЙБА (0.437) LOCKWASHER (.437) |
1 | |
| 17 | 71458 |
ШАЙБА WASHER |
1 | |
| 18 | 863396001 |
РАСПРЕДЕЛИТЕЛЬНАЯ КРЫШКА В СБОРЕ Screws, Grommets, Oil Seal, And Gasket Are Not Sold Seperately TIMING COVER ASSEMBLY Screws, Grommets, Oil Seal, And Gasket Are Not Sold Seperately |
1 | superseded |
| 19 | 863398 |
РУЛЕВОЕ КОЛЕСО РЕДУКТОРА RELUCTOR WHEEL |
1 | |
| 2 | 49146 |
ПРОБКА Pipe Standard Cooling PLUG Pipe Standard Cooling |
1 | disc. |
| 20 | 845941 |
ФИКСАТОР Camshaft RETAINER Camshaft |
1 | |
| 21 | 845943 |
ВИНТ (0.250-20 x 0.500) SCREW (.250-20 x .500) |
2 | |
| 22 | 17161T |
ЦЕПЬ Timing CHAIN Timing |
1 | superseded |
| 23 | 8116591 |
ЗВЕЗДОЧКА Camshaft SPROCKET Camshaft |
1 | |
| 24 | 845942 |
ВИНТ (0.312-18 x 0.750) SCREW (.312-18 x .750) |
3 | superseded |
| 25 | 17160 |
ЗВЕЗДОЧКА Crankshaft SPROCKET Crankshaft |
1 | superseded |
| 26 | 816565 |
ПРОБКА Колпачок (0.468) PLUG Cup (.468) |
1 | |
| 27 | 865615Q05 |
РЕМЕНЬ Поликлиновый Standard Cooling BELT Serpentine Standard Cooling |
1 | |
| 3 | 34897 |
ПРОКЛАДКА Water Pump GASKET Water Pump |
2 | |
| 4 | 864360 |
ИНФОРМАЦИОННАЯ НАКЛЕЙКА О МОМЕНТЕ ЗАЖИГАНИЯ TIMING DECAL |
1 | superseded |
| 5 | 35342 |
ШПИЛЬКА (0.312-24/0.375-16 x 2.5625) STUD (.312-24/.375-16 x 2.5625) |
2 | superseded |
| 6 | 32132 |
ВИНТ (0.375-16 x 1.750) SCREW (.375-16 x 1.750) |
1 | |
| 6 | 47688 |
ВИНТ (0.375-16 x 2.750) SCREW (.375-16 x 2.750) |
1 | |
| 7 | 807729T |
ШКИВ Standard Cooling PULLEY Standard Cooling |
1 | superseded |
| 7 | 865047T |
ШКИВ Water Pump Closed Cooling PULLEY Water Pump Closed Cooling |
1 | |
| 8 | 47277 |
ВИНТ (0.312-24 x 0.750) SCREW (.312-24 x .750) |
4 | |
| 9 | 864297001 |
ДАТЧИК В СБОРЕ Crankshaft Position SENSOR ASSEMBLY Crankshaft Position |
1 | superseded |
