| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 34353 |
ВИНТ (0.375-16 x 1.00) SCREW (.375-16 x 1.00) |
1 | |
| - | 37612 |
ВИНТ (0.375-16 x 1.250) SCREW (.375-16 x 1.250) |
1 | |
| - | 47688 |
ВИНТ (0.375-16 x 2.750) SCREW (.375-16 x 2.750) |
2 | |
| 1 | 72382 |
ШТИФТ Штифт Flywheel Housing Location PIN Dowel Flywheel Housing Location |
2 | superseded |
| 10 | 816730 |
ГАЙКА (0.250-20) NUT (.250-20) |
1 | superseded |
| 11 | 14242 |
БОЛТ (0.250-20 x 0.875) BOLT (.250-20 x .875) |
2 | |
| 12 | 14243 |
БОЛТ (0.250-20 x 1.750) BOLT (.250-20 x 1.750) |
1 | superseded |
| 13 | 11971 |
ГАЙКА (0.312-18) NUT (.312-18) |
2 | superseded |
| 14 | 14263 |
ШТИФТ Штифт Oil Seal Housing Locating PIN Dowel Oil Seal Housing Locating |
1 | |
| 15 | 818718A4 |
КРЫШКА В СБОРЕ COVER ASSEMBLY |
1 | |
| 16 | 86015 |
ПРОКЛАДКА GASKET |
1 | |
| 17 | 9558 |
МАХОВИК FLYWHEEL |
1 | superseded |
| 18 | 43504 |
ШТИФТ Штифт Flywheel PIN Dowel Flywheel |
2 | |
| 19 | 845757 |
ВИНТ (0.437-20 x 1.00) SCREW (.437-20 x 1.00) |
6 | superseded |
| 2 | 34270 |
КОМПЕНСАЦИОННАЯ ЗАГЛУШКА (1.625) Engine Core Hole EXPANSION PLUG (1.625) Engine Core Hole |
8 | |
| 20 | 862975A1 |
ВЕДУЩИЙ ДИСК В СБОРЕ (B/W 5000 / Hurth 630 Transmisions) DRIVEPLATE ASSEMBLY (B/W 5000 / Hurth 630 Transmisions) |
1 | |
| 21 | 34354 |
ВИНТ (0.375-16 x 1.50) (B/W 5000 / Hurth 630 Transmisions) SCREW (.375-16 x 1.50) (B/W 5000 / Hurth 630 Transmisions) |
6 | |
| 22 | 35048 |
СТОПОРНАЯ ШАЙБА (0.375) LOCKWASHER (.375) |
A/R | |
| 23 | 860125T |
ВЕДУЩИЙ ДИСК В СБОРЕ (B/W -71C/72C) DRIVEPLATE ASSEMBLY (B/W -71C/72C) |
1 | |
| 24 | 35091 |
ВИНТ (0.375-16 x 1.00) (B/W -71C/72C) SCREW (.375-16 x 1.00) (B/W -71C/72C) |
6 | |
| 25 | 814309A1 |
КОРПУС В СБОРЕ HOUSING ASSEMBLY |
1 | |
| 26 | 12304 |
ПРОБКА TIMING WINDOW PLUG TIMING WINDOW |
1 | |
| 27 | 38606 |
КРЫШКА/ПРОБКА (№10) CAPLUG (#10) |
1 | |
| 28 | 47277 |
ВИНТ (0.312-24 x 0.750) SCREW (.312-24 x .750) |
1 | |
| 29 | 400247 |
СТОПОРНАЯ ШАЙБА (M8) LOCKWASHER (M8) |
1 | |
| 3 | 48340 |
ПРОБКА (0.250-18 x 0.41) Oil Galley PLUG (.250-18 x .41) Oil Galley |
4 | superseded |
| 30 | 861316 |
ШПИЛЬКА STUD (.375-16 x 2.750) Special |
2 | |
| 31 | 82671112 |
ГАЙКА (.375-16) NUT (.375-16) |
2 | |
| 32 | 98253 |
ВИНТ (0.250-20 x 0.500) SCREW (.250-20 x .500) |
5 | |
| 33 | 26992 |
СТОПОРНАЯ ШАЙБА (0.250), нержавеющая сталь LOCKWASHER (.250) Stainless Steel |
5 | |
| 4 | 72640 |
ПРОБКА Camshaft Bearing Hole PLUG Camshaft Bearing Hole |
1 | |
| 5 | 14827 |
ШПИЛЬКА (0.250-20 x 2.180) STUD (.250-20 x 2.180) |
2 | |
| 6 | 881715 |
ПРОКЛАДКА Crankshaft Oil Seal Housing GASKET Crankshaft Oil Seal Housing |
1 | |
| 7 | 852940 |
КОРПУС В СБОРЕ Со шпильками Crankshaft Oil Seal HOUSING ASSEMBLY With Studs Crankshaft Oil Seal |
1 | |
| 8 | 852941 |
УПЛОТНЕНИЕ Crankshaft Oil SEAL Crankshaft Oil |
1 | |
| 9 | 11989 |
ШПИЛЬКА (0.312-18 x 1.6718) STUD (.312-18 x 1.6718) |
2 |
