| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 863489 |
РУКАВ Power Steering Cooler to Check Valve HOSE Power Steering Cooler to Check Valve |
1 | |
| 10 | 863781 |
РУКАВ Fuel Cooler to Accumulator Housing HOSE Fuel Cooler to Accumulator Housing |
1 | |
| 11 | 864506 |
РУКАВ Heat Exchanger to Thermostat Housing HOSE Heat Exchanger to Thermostat Housing |
1 | |
| 12 | 864507 |
РУКАВ Heat Exchanger to Thermostat Housing HOSE Heat Exchanger to Thermostat Housing |
1 | |
| 13 | 864532 |
РУКАВ Heat Exchanger to Elbow (Starboard) (Without Riser) HOSE Heat Exchanger to Elbow (Starboard) (Without Riser) |
1 | |
| 13 | 864934 |
РУКАВ Heat Exchanger to Elbow (Starboard) (1.7 inch and 3 Inch Riser) HOSE Heat Exchanger to Elbow (Starboard) (1.7 inch and 3 Inch Riser) |
1 | |
| 13 | 866079 |
РУКАВ Heat Exchanger to Elbow (Starboard) (6 Inch Riser) HOSE Heat Exchanger to Elbow (Starboard) (6 Inch Riser) |
1 | |
| 14 | 864726 |
РУКАВ Heat Exchanger to Elbow (Port) (Without Riser) HOSE Heat Exchanger to Elbow (Port) (Without Riser) |
1 | |
| 14 | 864932 |
РУКАВ Heat Exchanger to Elbow (Port) (1.7 Inch and 3 Inch Riser) HOSE Heat Exchanger to Elbow (Port) (1.7 Inch and 3 Inch Riser) |
1 | |
| 14 | 866078 |
РУКАВ Heat Exchanger to Elbow (Port) (6 Inch Riser) HOSE Heat Exchanger to Elbow (Port) (6 Inch Riser) |
1 | |
| 15 | 8636111 |
РУКАВ Sea Pump to Power Steering Cooler HOSE Sea Pump to Power Steering Cooler |
1 | disc. |
| 16 | 815504212 |
ЗАЖИМ Червячная передача Hose CLAMP Worm Gear Hose |
1 | |
| 17 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) Hose CLAMP Worm Gear (1.56 Diameter) Hose |
1 | |
| 18 | 815504222 |
ЗАЖИМ Червячная передача (диаметр 1.98) Hose CLAMP Worm Gear (1.98 DIameter) Hose |
1 | superseded |
| 19 | 815504228 |
ЗАЖИМ Червячная передача Hose CLAMP Worm Gear Hose |
1 | |
| 2 | 864206A1 |
ОБРАТНЫЙ КЛАПАН В СБОРЕ CHECK VALVE ASSEMBLY |
1 | |
| 20 | 815504232 |
ЗАЖИМ Червячная передача (диаметр 2.50) Hose CLAMP Worm Gear (2.50 Diameter) Hose |
1 | |
| 21 | 864886 |
РУКАВ Heat Exchanger to Circulating Pump HOSE Heat Exchanger to Circulating Pump |
1 | |
| 22 | 815504224 |
ЗАЖИМ Червячная передача Hose CLAMP Worm Gear Hose |
1 | |
| 23 | 864395T01 |
ТЕПЛООБМЕННИК Closed Cooling HEAT EXCHANGER Closed Cooling |
1 | |
| 24 | 864708 |
КРЫШКА COVER End Cap |
2 | |
| 25 | 866152 |
УПЛОТНЕНИЕ End Cover SEAL End Cover |
2 | superseded |
| 26 | 814877 |
БОЛТ BOLT |
2 | disc. |
| 27 | 814878 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Специальный O-RING Special |
2 | superseded |
| 28 | 8148791 |
ПРОБКА Pressure CAP Pressure |
1 | |
| 29 | 805559 |
ВИНТ (0.375-16 x 0.875), нержавеющая сталь SCREW (.375-16 x .875) Stainless Steel |
1 | |
| 3 | 863811 |
РУКАВ Check Valve to Fuel Cooler HOSE Check Valve to Fuel Cooler |
1 | |
| 30 | 34353 |
ВИНТ (0.375-16 x 1.00) SCREW (.375-16 x 1.00) |
2 | |
| 31 | 815504396 |
ЗАЖИМ Червячная передача Heat Exchanger CLAMP Worm Gear Heat Exchanger |
1 | |
| 32 | 71587A10 |
КОМПЛЕКТ ДЛЯ ВОССТАНОВЛЕНИЯ Охлаждающая жидкость RECOVERY KIT Coolant |
1 | |
| 33 | 71587A11 |
БАЧОК Пластик Coolant Recovery Kit BOTTLE Plastic Coolant Recovery Kit |
1 | |
| 34 | 72058 |
ПРОБКА Coolant Recovery Bottle CAP Bottle Coolant Recovery Bottle |
1 | |
| 35 | 863841T |
ТРУБА Вода Brass (Compact Hydralic Steering) TUBE Water Brass (Compact Hydralic Steering) |
1 | |
| 36 | 18431 |
НАКЛАДКА Heat Exchanger PAD Heat Exchanger |
1 | |
| 37 | 864494T |
КРОНШТЕЙН Cooler BRACKET Cooler |
1 | |
| 38 | 4285069 |
РУКАВ (Общая длина 44.00") (Cut to 6 Inch Length) HOSE (44.00 Inches Bulk) (Cut to 6 Inch Length) |
1 | superseded |
| 39 | 806608A02 |
УЗЕЛ ПРОБКИ (0.500-13), синий PLUG ASSEMBLY (.500-13) Blue |
1 | superseded |
| 4 | 864551 |
РУКАВ Intake Bypass to Circulating Pump HOSE Intake Bypass to Circulating Pump |
1 | |
| 40 | 8M2000926 |
УПЛОТНЕНИЕ SEAL |
1 | superseded |
| 5 | 864431 |
РУКАВ Distribution Housing to Heat Exchanger HOSE Distribution Housing to Heat Exchanger |
1 | |
| 6 | 864713 |
РУКАВ Thermostat Housing to Upper Manifold (Starboard) (Without Riser) HOSE Thermostat Housing to Upper Manifold (Starboard) (Without Riser) |
1 | |
| 6 | 864933 |
РУКАВ Thermostat Housing to Upper Manifold (Starboard) (1.7 inch and 3 Inch Riser) HOSE Thermostat Housing to Upper Manifold (Starboard) (1.7 inch and 3 Inch Riser) |
1 | |
| 6 | 866081 |
РУКАВ Thermostat Housing to Upper Manifold (Starboard) (6 Inch Riser) HOSE Thermostat Housing to Upper Manifold (Starboard) (6 Inch Riser) |
1 | |
| 7 | 864714 |
РУКАВ Thermostat Housing to Upper Manifold (Port) (Without Riser) HOSE Thermostat Housing to Upper Manifold (Port) (Without Riser) |
1 | |
| 7 | 864931 |
РУКАВ Thermostat Housing to Upper Manifold (Port) (1.7 inch and 3 Inch Riser) HOSE Thermostat Housing to Upper Manifold (Port) (1.7 inch and 3 Inch Riser) |
1 | |
| 7 | 866080 |
РУКАВ Thermostat Housing to Upper Manifold (Port) (6 Inch Riser) HOSE Thermostat Housing to Upper Manifold (Port) (6 Inch Riser) |
1 | |
| 8 | 864534 |
РУКАВ Thermostat Housing to Lower Manifold (Starboard) HOSE Thermostat Housing to Lower Manifold (Starboard) |
1 | |
| 9 | 864575 |
РУКАВ Thermostat Housing to Lower Manifold (Port) HOSE Thermostat Housing to Lower Manifold (Port) |
1 | |
| NS | 774572 |
РУКАВ (Общая длина 48.00") HOSE (48.00 Inches Bulk) |
1 |
