| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 807756A02 |
КОМПЛЕКТ ПРОКЛАДОК Engine Overhaul GASKET SET Engine Overhaul |
1 | |
| - | 879150A31 |
ЛОНГ-БЛОК (4.3L) LONG BLOCK (4.3L) |
1 | disc. |
| 1 | 879194366 |
НАСОС В СБОРЕ PUMP ASSEMBLY |
1 | superseded |
| 10 | 885192 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING |
1 | |
| 11 | 884018 |
ВИНТ SCREW |
1 | superseded |
| 12 | 807730T |
ШКИВ Crankshaft PULLEY Crankshaft |
1 | |
| 13 | 34352 |
ВИНТ (0.375-24 x 0.875) SCREW (.375-24 x .875) |
3 | |
| 14 | 888776T |
ВИБРОГАСИТЕЛЬ HARMONIC BALANCER |
1 | |
| 15 | 32515 |
ВИНТ (0.437-20 x 2.50) SCREW (.437-20 x 2.50) |
1 | superseded |
| 16 | 39131 |
СТОПОРНАЯ ШАЙБА (0.437) LOCKWASHER (.437) |
1 | |
| 17 | 71458 |
ШАЙБА WASHER |
1 | |
| 18 | 879194362 |
КРЫШКА В СБОРЕ Распределение COVER ASSEMBLY Timing |
1 | disc. |
| 19 | 879194365 |
УПЛОТНЕНИЕ Oil SEAL Oil |
1 | superseded |
| 2 | 879194370 |
ПРОБКА Pipe (Standard Cooling) PLUG Pipe (Standard Cooling) |
1 | disc. |
| 20 | 879194369 |
БОЛТ Timing Cover BOLT Timing Cover |
6 | |
| 21 | 888782 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Timing Cover GROMMET Timing Cover |
6 | |
| 22 | 8M0069696 |
ПРОКЛАДКА GASKET |
1 | |
| 23 | 816565 |
ПРОБКА Колпачок (0.468) PLUG Cup (.468) |
1 | |
| 24 | 879194344 |
РУЛЕВОЕ КОЛЕСО РЕДУКТОРА RELUCTOR WHEEL |
1 | |
| 25 | 824333 |
ФИКСАТОР Camshaft RETAINER Camshaft |
1 | |
| 26 | 824334 |
ВИНТ (0.250-20 x 0.500) SCREW (.250-20 x .500) |
2 | |
| 27 | 8M0050619 |
НАБОР РАСПРЕДЕЛИТЕЛЬНЫХ ЦЕПЕЙ Цепь и звездочки TIMING CHAIN SET Chain and Sprockets |
1 | |
| 28 | NSS |
НЕ ПРОДАЕТСЯ ОТДЕЛЬНО Camshaft Sprocket NOT SOLD SEPARATE Camshaft Sprocket |
1 | |
| 29 | NSS |
НЕ ПРОДАЕТСЯ ОТДЕЛЬНО Crankshaft Sprocket NOT SOLD SEPARATE Crankshaft Sprocket |
1 | |
| 3 | 879194367 |
ПРОКЛАДКА Water Pump GASKET Water Pump |
2 | |
| 30 | 824329 |
ВИНТ (0.312-18 x 0.750) SCREW (.312-18 x .750) |
3 | disc. |
| 31 | 865615004 |
РЕМЕНЬ (Alpha-Standard Cooling)(Power Steering) BELT (Alpha-Standard Cooling)(Power Steering) |
1 | superseded |
| 31 | 865615009 |
РЕМЕНЬ (Alpha-Standard Cooling)(Compact Hydraulic Steering) BELT (Alpha-Standard Cooling)(Compact Hydraulic Steering) |
1 | superseded |
| 31 | 865615003 |
РЕМЕНЬ (Alpha-Closed Cooling)(Bravo)(Power Steering) BELT (Alpha-Closed Cooling)(Bravo)(Power Steering) |
1 | superseded |
| 31 | 865615008 |
РЕМЕНЬ (Alpha-Closed Cooling)(Bravo)(Compact Hydraulic Steering) BELT (Alpha-Closed Cooling)(Bravo)(Compact Hydraulic Steering) |
1 | superseded |
| 4 | 860346 |
ФИТИНГ Коленчатый патрубок (90 градусов) (0.750) (Closed Cooling) FITTING Elbow (90 Degree) (.750) (Closed Cooling) |
1 | |
| 5 | 35342 |
ШПИЛЬКА (0.312-24/0.375-16 x 2.5625) STUD (.312-24/.375-16 x 2.5625) |
2 | superseded |
| 6 | 32132 |
ВИНТ (0.375-16 x 1.750) SCREW (.375-16 x 1.750) |
2 | |
| 6 | 47688 |
ВИНТ (0.375-16 x 2.750) SCREW (.375-16 x 2.750) |
1 | |
| 7 | 807729T |
ШКИВ PULLEY |
1 | superseded |
| 8 | 47277 |
ВИНТ (0.312-24 x 0.750) SCREW (.312-24 x .750) |
4 | |
| 9 | 879194363 |
ДАТЧИК В СБОРЕ Crankshaft Position SENSOR ASSEMBLY Crankshaft Position |
1 |
