| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 860315A1 |
ТРУБА Hose Extender (Compact Hydralic Steering) (Cut to 10.50 Inch Length) TUBE Hose Extender (Compact Hydralic Steering) (Cut to 10.50 Inch Length) |
1 | |
| 10 | 807661 |
РУКАВ Transom to Power Steering Cooler (Alpha) HOSE Transom to Power Steering Cooler (Alpha) |
1 | |
| 11 | 865672079 |
РУКАВ (Общая длина 96.00") Sea Water Pump to Drive (Bravo) HOSE (96.00 Inches Bulk) Sea Water Pump to Drive (Bravo) |
1 | superseded |
| 12 | 862210A01 |
КОМПЛЕКТ КОЛЕНЧАТОГО ПАТРУБКА Слив ELBOW KIT Drain |
2 | |
| 13 | 806608A02 |
УЗЕЛ ПРОБКИ (0.500-13), синий Drain Fitting PLUG ASSEMBLY (.500-13) Blue Drain Fitting |
9 | superseded |
| 14 | 8M2000926 |
УПЛОТНЕНИЕ SEAL |
9 | superseded |
| 15 | 860088 |
ВТУЛКА BUSHING |
3 | superseded |
| 16 | 46982 |
ФИТИНГ (90 градусов) FITTING (90 Degree) |
1 | |
| 17 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) Hose CLAMP Worm Gear (1.56 Diameter) Hose |
4 | |
| 18 | 815504222 |
ЗАЖИМ Червячная передача (диаметр 1.98) Hose CLAMP Worm Gear (1.98 DIameter) Hose |
11 | superseded |
| 19 | 815504232 |
ЗАЖИМ Червячная передача (диаметр 2.50) Hose CLAMP Worm Gear (2.50 Diameter) Hose |
2 | |
| 2 | 806616 |
ЗАЖИМ Water Tube CLAMP Water Tube |
1 | |
| 20 | 815504220 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
3 | |
| 21 | 865672013 |
РУКАВ (4.00") HOSE (4.00 Inches) |
1 | superseded |
| 22 | 865362 |
БЫСТРОРАЗЪЕМНЫЙ QUICK CONNECT |
1 | |
| 23 | 865324 |
БЫСТРОРАЗЪЕМНЫЙ QUICK CONNECT |
2 | |
| 24 | 8M2005622 |
ФИТИНГ Редуктор (M28 x 0.250) FITTING Reducer (M28 x .250) |
1 | |
| 3 | 8079923 |
КРЫШКА Hose Clamp End COVER Hose Clamp End |
AR | superseded |
| 4 | 865092 |
РУКАВ Power Steering Cooler to Thermostat Housing HOSE Power Steering Cooler to Thermostat Housing |
1 | |
| 5 | 861590A05 |
ШЛАНГ В СБОРЕ Circulating Pump to Thermostat Housing HOSE ASSEMBLY Circulating Pump to Thermostat Housing |
1 | |
| 6 | 864977 |
РУКАВ Thermostat Housing to Elbow HOSE Thermostat Housing to Elbow |
2 | disc. |
| 7 | 862124 |
РУКАВ Thermostat Housing to Starboard Manifold HOSE Thermostat Housing to Starboard Manifold |
1 | |
| 8 | 862139 |
РУКАВ Thermostat Housing to Port Exhaust Manifold HOSE Thermostat Housing to Port Exhaust Manifold |
1 | |
| 9 | 860205 |
РУКАВ Sea Pump to Power Steering Cooler (Bravo) [1A299999] & Below HOSE Sea Pump to Power Steering Cooler (Bravo) [1A299999] & Below |
1 | |
| 9 | 8636111 |
РУКАВ Sea Pump to Power Steering Cooler (Bravo) [1A300000] & Up HOSE Sea Pump to Power Steering Cooler (Bravo) [1A300000] & Up |
1 | disc. |
