| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 863732T1 |
КРОНШТЕЙН Remote Oil Filter Includes Fitting BRACKET Remote Oil Filter Includes Fitting |
1 | |
| 10 | 22937 |
ШАЙБА WASHER |
1 | |
| 10 | 35044 |
ШАЙБА (0.281 x 0.625 x 0.065), нержавеющая сталь (SEACORE) WASHER (.281 x .625 x .065) Stainless Steel (SEACORE) |
1 | |
| 11 | 866401 |
РУКАВ Oil, Filter Base to Block HOSE Oil, Filter Base to Block |
1 | |
| 11 | 8M2000827 |
РУКАВ Oil, Filter Base to Block V-Drive HOSE Oil, Filter Base to Block V-Drive |
1 | disc. |
| 12 | 866402 |
РУКАВ Oil, Filter to Cooler HOSE Oil, Filter to Cooler |
1 | |
| 12 | 8M2000828 |
РУКАВ Oil, Filter to Cooler V-Drive HOSE Oil, Filter to Cooler V-Drive |
1 | |
| 13 | 401366 |
ГАЙКА (M6), нержавеющая сталь NUT (M6) Stainless Steel |
1 | |
| 14 | 807445T |
ЗАЖИМ Cooler Bracket CLAMP Cooler Bracket |
1 | |
| 15 | 4000327 |
ВИНТ (M6 x 14) SCREW (M6 x 14) |
2 | |
| 16 | 862870T |
ПЕРЕХОДНИК Oil Filter ADAPTER Oil Filter |
1 | |
| 17 | 862957 |
УПЛОТНЕНИЕ Oil Filter Adaptor SEAL Oil Filter Adaptor |
1 | |
| 18 | 42077 |
УПЛОТНЕНИЕ Swivel Tube SEAL Swivel Tube |
1 | |
| 19 | 862958 |
ФИТИНГ Oil Filter Adaptor FITTING Oil Filter Adaptor |
1 | |
| 2 | 866340Q03 |
ФИЛЬТР Масло марки Quicksilver FILTER Oil |
1 | |
| 20 | 879288T46 |
ОХЛАДИТЕЛЬ Oil COOLER Oil |
1 | |
| 21 | 863905T |
КРОНШТЕЙН Oil Cooler BRACKET Oil Cooler |
1 | |
| 22 | 866626T |
КРОНШТЕЙН Front Lifting Eye BRACKET Front Lifting Eye |
1 | disc. |
| 23 | 866703 |
КРОНШТЕЙН Remote Oil V-Drive BRACKET Remote Oil V-Drive |
1 | disc. |
| 24 | 4010816 |
ВИНТ Шестигранный фланец (M10 x 16), нержавеющая сталь To Head SCREW (M10 x 16) Hex Flange - Stainless Steel To Head |
2 | |
| 3 | 865262A01 |
КРОНШТЕЙН В СБОРЕ BRACKET ASSEMBLY |
1 | superseded |
| 4 | 4010720 |
ВИНТ (M8 x 20) SCREW (M8 x 20) |
2 | |
| 5 | 863485 |
ФИТИНГ Part of Remote Oil Filter Bracket FITTING Part of Remote Oil Filter Bracket |
1 | |
| 6 | 4010820 |
ВИНТ Шестигранный фланец (M10 x 20), нержавеющая сталь SCREW (M10 x 20) Hex Flange - Stainless Steel |
2 | |
| 7 | 863915 |
РУКАВ Oil, Cooler to Adaptor HOSE Oil, Cooler to Adaptor |
1 | |
| 8 | 805632 |
СОЕДИНИТЕЛЬ Filter Adaptor CONNECTOR Filter Adaptor |
1 | |
| 9 | 805563 |
СОЕДИНИТЕЛЬ (NPTF 0.500" к инвертированной свече зажигания 0.500") CONNECTOR (.500 Inch NPTF To .500 Inch Inverted Flare) |
1 |
