| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 862342T |
КРОНШТЕЙН Remote Oil Filter BRACKET Remote Oil Filter |
1 | |
| 10 | 806328 |
ФИТИНГ Oil Adaptor FITTING Oil Adaptor |
1 | |
| 11 | 863899 |
РУКАВ Oil, Filter to Adaptor HOSE Oil, Filter to Adaptor |
1 | |
| 11 | 863902 |
РУКАВ Oil, Filter to Adaptor V-Drive HOSE Oil, Filter to Adaptor V-Drive |
1 | |
| 12 | 863900 |
РУКАВ Oil, Filter to Cooler HOSE Oil, Filter to Cooler |
1 | |
| 12 | 8639011 |
РУКАВ Oil, Filter to Cooler V-Drive HOSE Oil, Filter to Cooler V-Drive |
1 | |
| 13 | 424632 |
ШПИЛЬКА (M8 x 37.1) STUD (M8 x 37.1) |
1 | |
| 14 | 34948 |
ПРОСТАВКА SPACER |
1 | |
| 15 | 475451 |
ЗАЖИМ CLIP |
2 | |
| 16 | 862870T |
ПЕРЕХОДНИК Oil Filter ADAPTER Oil Filter |
1 | |
| 17 | 862957 |
УПЛОТНЕНИЕ Oil Filter Adaptor SEAL Oil Filter Adaptor |
1 | |
| 18 | 42077 |
УПЛОТНЕНИЕ Swivel Tube SEAL Swivel Tube |
1 | |
| 19 | 862958 |
ФИТИНГ Oil Filter Adaptor FITTING Oil Filter Adaptor |
1 | |
| 2 | 802885Q |
ФИЛЬТР Масло FILTER Oil |
1 | superseded |
| 20 | 863904T |
ОХЛАДИТЕЛЬ Oil COOLER Oil |
1 | |
| 21 | 863905T |
КРОНШТЕЙН Oil Cooler BRACKET Oil Cooler |
1 | |
| 22 | 4000327 |
ВИНТ (M6 x 14) SCREW (M6 x 14) |
2 | |
| 23 | 807445T |
ЗАЖИМ Cooler Bracket CLAMP Cooler Bracket |
1 | |
| 24 | 401366 |
ГАЙКА (M6), нержавеющая сталь NUT (M6) Stainless Steel |
1 | |
| 25 | 22937 |
ШАЙБА WASHER |
1 | |
| 26 | 805563 |
СОЕДИНИТЕЛЬ (NPTF 0.500" к инвертированной свече зажигания 0.500") CONNECTOR (.500 Inch NPTF To .500 Inch Inverted Flare) |
1 | |
| 27 | 863915 |
РУКАВ Oil, Cooler to Adaptor HOSE Oil, Cooler to Adaptor |
1 | |
| 28 | 805632 |
СОЕДИНИТЕЛЬ Filter Adaptor CONNECTOR Filter Adaptor |
1 | |
| 3 | 865262A01 |
КРОНШТЕЙН В СБОРЕ BRACKET ASSEMBLY |
1 | superseded |
| 4 | 4010720 |
ВИНТ (M8 x 20) SCREW (M8 x 20) |
2 | |
| 5 | 8629102 |
КРОНШТЕЙН Support BRACKET Support |
1 | |
| 5 | 8629101 |
КРОНШТЕЙН (V-Drive) BRACKET (V-Drive) |
1 | |
| 6 | 4010716 |
ВИНТ (M8 x 16) Flange SCREW (M8 x 16) Flange |
1 | |
| 7 | 4002030 |
ГАЙКА (M8) NUT (M8) |
3 | |
| 8 | 12038 |
ШАЙБА WASHER |
3 | superseded |
| 9 | 42077 |
УПЛОТНЕНИЕ SEAL |
1 |
