| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 881653 |
ПОДДОН Масло PAN Oil |
1 | superseded |
| 10 | 861982 |
ПРОБКА Vinyl CAP Vinyl |
1 | |
| 11 | 805524 |
ЗАЖИМ CLIP |
1 | |
| 12 | 49955 |
ПРОКЛАДКА Drain (V-Drive) GASKET Drain (V-Drive) |
1 | superseded |
| 13 | 863389 |
ФИТИНГ Oil Gauge Tube (V-Drive) FITTING Oil Gauge Tube (V-Drive) |
1 | superseded |
| 14 | 19697 |
КОЛЕНЧАТЫЙ (V-Drive) ELBOW (V-Drive) |
1 | |
| 15 | 863408 |
ТРУБА Engine Oil Gauge (V-Drive) TUBE Engine Oil Gauge (V-Drive) |
1 | |
| 16 | 4000328 |
ВИНТ (M6 x 16) SCREW (M6 x 16) |
1 | superseded |
| 17 | 65653 |
ЗАЖИМ (V-Drive) CLIP (V-Drive) |
1 | |
| 18 | 86194210 |
УКАЗАТЕЛЬ Oil Level (V-Drive) GAUGE Oil Level (V-Drive) |
1 | |
| 19 | 898101392 |
БОЛТ (M8 x 30) BOLT (M8 x 30) |
13 | |
| 2 | 881612 |
ПРОКЛАДКА Oil Pan GASKET Oil Pan |
1 | |
| 3 | 863406 |
ТРУБА Engine Oil Gauge ( In-Line Starboard) TUBE Engine Oil Gauge ( In-Line Starboard) |
1 | |
| 4 | 807804 |
ФИТИНГ Oil Gauge Tube (In-Line) FITTING Oil Gauge Tube (In-Line) |
2 | |
| 5 | 49955 |
ПРОКЛАДКА Drain (In-Line) GASKET Drain (In-Line) |
2 | superseded |
| 6 | 863407 |
ТРУБА Engine Oil Gauge (In-Line Port) TUBE Engine Oil Gauge (In-Line Port) |
1 | |
| 7 | 86194211 |
УКАЗАТЕЛЬ Oil Level (In-Line) GAUGE Oil Level (In-Line) |
1 | |
| 8 | 4000328 |
ВИНТ (M6 x 16) SCREW (M6 x 16) |
2 | superseded |
| 9 | 65653 |
ЗАЖИМ CLIP |
2 | |
| NS | 883922 |
ОТРАЖАТЕЛЬНЫЙ ЩИТОК Oil Pan BAFFLE Oil Pan |
1 | disc. |
| NS | 883923 |
ВИНТ (M6 x 20) SCREW (M6 x 20) |
AR |
