| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 843073A03 |
КОМПЛЕКТ ПРОКЛАДОК/УПЛОТНИТЕЛЕЙ Капитальный ремонт двигателя - NOTE: See Gasket/Seal Set - Engine Overhaul Section For Complete Parts Listing GASKET/SEAL SET Engine Overhaul - NOTE: See Gasket/Seal Set - Engine Overhaul Section For Complete Parts Listing |
1 | superseded |
| - | 841178A1 |
ЧАСТИЧНЫЙ УЗЕЛ ДВИГАТЕЛЯ PARTIAL ENGINE ASSEMBLY |
1 | disc. |
| 1 | 861942T9 |
ЩУП Уровень масла DIPSTICK Oil Level |
1 | |
| 10 | 811683 |
ШПИЛЬКА (0.375-16/0.500-12 x 5.500) STUD (.375-16/.500-12 x 5.500) |
4 | superseded |
| 11 | 845601T |
ОТРАЖАТЕЛЬНЫЙ ЩИТОК Маслоотражатель BAFFLE Oil Deflector |
1 | superseded |
| 12 | 845602 |
ГАЙКА (.375-16) NUT (.375-16) |
5 | |
| 13 | 845628 |
ПРОКЛАДКА Oil Pan GASKET Oil Pan |
1 | |
| 14 | 845668T |
ПОДДОН В СБОРЕ Масло PAN ASSEMBLY Oil |
1 | superseded |
| 15 | 809911 |
ВИНТ Слив масла (M12 x 1.75) SCREW Oil Drain (M12 x 1.75) |
1 | superseded |
| 16 | 49955 |
ПРОКЛАДКА Oil Drain Screw GASKET Oil Drain Screw |
1 | superseded |
| 17 | 841389 |
ВИНТ (0.312-18 x 0.620) SCREW (.312-18 x .620) |
20 | |
| 18 | 865281A02 |
КОМПЛЕКТ РУКАВА Слив масла (38.00") - Bravo Models HOSE KIT Oil Drain (38.00 Inches) - Bravo Models |
1 | |
| 18 | 865280A02 |
КОМПЛЕКТ РУКАВА Слив масла (92.00") - Driveline Models HOSE KIT Oil Drain (92.00 Inches) - Driveline Models |
1 | |
| 19 | 863481 |
ЗАЖИМ CLAMP |
1 | |
| 2 | 841227 |
J-ЗАЖИМ Dipstick Tube Support J CLIP Dipstick Tube Support |
1 | superseded |
| 20 | 862827 |
ТРОС В СБОРЕ TETHER ASSEMBLY |
1 | |
| 21 | 805524 |
ЗАЖИМ CLIP |
1 | |
| 22 | 49955 |
ПРОКЛАДКА GASKET |
1 | superseded |
| 3 | 843141A2 |
ТРУБА В СБОРЕ Щуп TUBE ASSEMBLY Dipstick |
1 | superseded |
| 4 | 62704 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.362 x 0.103) O-RING (.362 x .103) |
1 | |
| 5 | 14761 |
ВАЛ И ФИКСАТОР SHAFT AND RETAINER |
1 | superseded |
| 6 | 36183 |
ФИКСАТОР RETAINER |
1 | |
| 7 | 827643 |
НАСОС В СБОРЕ Масло PUMP ASSEMBLY Oil |
1 | |
| 8 | FI5000254 |
ПРОКЛАДКА Oil Pump Cover GASKET Oil Pump Cover |
1 | disc. |
| 9 | 845599 |
ШПИЛЬКА (0.375-16/0.438-14 x 3.00) STUD (.375-16/.438-14 x 3.00) |
1 |
