| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 847145T1 |
КОМПЛЕКТ ОПОРЫ И РЫЧАГА Универсальный шарнир SUPPORT AND LEVER KIT Universal Joint |
1 | |
| - | 847123A1 |
ОПОРА В СБОРЕ Универсальный шарнир SUPPORT ASSEMBLY Universal Joint |
1 | superseded |
| 1 | 14746A5 |
ТРАНСМИССИЯ В СБОРЕ Complete - Design I - Huber Model Number HM 600 TRANSMISSION ASSEMBLY Complete - Design I - Huber Model Number HM 600 |
1 | disc. |
| 1 | 841919A06 |
ТРАНСМИССИЯ В СБОРЕ Complete - Design II - BAM Model Number 1500 TRANSMISSION ASSEMBLY Complete - Design II - BAM Model Number 1500 |
1 | disc. |
| 1 | 14746A4 |
ТРАНСМИССИЯ В СБОРЕ - Design I - Huber Model Number HM 600 TRANSMISSION ASSEMBLY - Design I - Huber Model Number HM 600 |
1 | disc. |
| 1 | 841919A07 |
ТРАНСМИССИЯ В СБОРЕ - Design II - BAM Model Number 1500 TRANSMISSION ASSEMBLY - Design II - BAM Model Number 1500 |
1 | disc. |
| 10 | 847031 |
ШПИЛЬКА (0.437-14/0.437-20 x 2.750) STUD (.437-14/.437-20 x 2.750) |
2 | |
| 10 | 847030 |
ШПИЛЬКА (0.437-14/0.437-20 x 3.00) STUD (.437-14/.437-20 x 3.00) |
6 | |
| 11 | 842922 |
ШАЙБА (0.450 x 0.750 x 0.060), нержавеющая сталь WASHER (.450 x .750 x .060) Stainless Steel |
8 | |
| 12 | 34933 |
ГАЙКА (.437-20), нержавеющая сталь NUT (.437-20) Stainless Steel |
8 | superseded |
| 13 | 847052 |
РЫЧАГ Переключение передач LEVER Shift |
1 | |
| 14 | 8267096 |
ГАЙКА (№10-32), нержавеющая сталь NUT (#10-32) Stainless Steel |
5 | |
| 15 | 846787 |
ПРОСТАВКА Rod End SPACER Rod End |
3 | |
| 16 | 846786 |
КОНЦЕВАЯ ЧАСТЬ ТЯГИ ROD END |
3 | |
| 17 | 34994 |
ВИНТ (№10-32 x 1.00), нержавеющая сталь SCREW (#10-32 x 1.00) Stainless Steel |
5 | disc. |
| 18 | 68219 |
ГАЙКА (№10-32), нержавеющая сталь NUT (#10-32) Stainless Steel |
3 | |
| 19 | 846964 |
ШПИЛЬКА (№10-32 x 2.09) Shift Rod STUD (#10-32 x 2.09) Shift Rod |
1 | |
| 2 | 47613 |
ПЕРЕКЛЮЧАТЕЛЬ Neutral Safety SWITCH Neutral Safety |
1 | |
| 20 | 846341 |
КРОНШТЕЙН Shift Cable BRACKET Shift Cable |
1 | |
| 21 | 846344 |
ПРОСТАВКА Cable Bracket SPACER Cable Bracket |
1 | |
| 22 | 826709113 |
ГАЙКА (0.375-24), нержавеющая сталь NUT (.375-24) Stainless Steel |
1 | superseded |
| 23 | 841388 |
ШАЙБА (0.410 x 0.810 x 0.050), нержавеющая сталь WASHER (.410 x .810 x .050) Stainless Steel |
3 | |
| 24 | 846783 |
ШАЙБА (0.562 x 1.250 x 0.062), нейлон WASHER (.562 x 1.250 x .062) Nylon |
1 | |
| 25 | 812707 |
ВТУЛКА BUSHING |
1 | |
| 26 | 847025 |
ARM Трос реверса ARM Shift Cable |
1 | |
| 27 | 847175 |
ПЛАСТИНА В СБОРЕ Опора тяги реверса PLATE ASSEMBLY Shift Linkage Mount |
1 | superseded |
| 28 | 846453 |
ШПИЛЬКА (0.375-16 x 1.250) Mounting Plate STUD (.375-16 x 1.250) Mounting Plate |
2 | |
| 29 | 826709112 |
ГАЙКА (0.375-16), нержавеющая сталь NUT (.375-16) Stainless Steel |
2 | |
| 3 | 47629 |
КОЛЕНЧАТЫЙ 90 градусов Transmission To Oil Hose ELBOW 90 Degree Transmission To Oil Hose |
2 | |
| 30 | 8469611 |
КОРПУС УНИВЕРСАЛЬНАЯ ШАРНИРНАЯ ОПОРА HOUSING Universal Joint Support |
1 | superseded |
| 31 | 846497 |
УПЛОТНЕНИЕ Inner Coupler SEAL Inner Coupler |
1 | |
| 32 | 846477A1 |
НАБОР ПОДШИПНИКОВ Колпачок и конус Rear Coupler BEARING SET Cup And Cone Rear Coupler |
1 | |
| 33 | 846960 |
ВАЛ Coupling SHAFT Coupling |
1 | superseded |
| 34 | 82670910 |
ГАЙКА (0.312-18), нержавеющая сталь NUT (.312-18) Stainless Steel |
1 | |
| 35 | 846967 |
ШАЙБА (0.376 x 1.430 x 0.250) WASHER (.376 x 1.430 x .250) |
2 | |
| 36 | 847027 |
УПЛОТНЕНИЕ Coupler SEAL Coupler |
1 | |
| 37 | 847209 |
ВИНТ С БУРТИКОМ (.375-16) SHOULDER SCREW (.375-16) |
1 | |
| 38 | 846695A1 |
НАБОР ПОДШИПНИКОВ Колпачок и конус Front Coupler BEARING SET Cup And Cone Front Coupler |
1 | |
| 39 | 847029A1 |
НАБОР ПРОКЛАДОК Bearing SHIM SET Bearing |
2 | |
| 4 | 88517 |
ФИТИНГ Редуктор Transmission Elbow FITTING Reducing Transmission Elbow |
1 | |
| 40 | 841807 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (3.500 x 0.103) O-RING (3.500 x .103) |
1 | |
| 41 | 847033 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.620 x 0.09) O-RING (.620 x .09) |
1 | |
| 42 | 847034 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (1.310 x 0.09) O-RING (1.310 x .09) |
1 | |
| 43 | 8470121 |
ПРОСТАВКА Универсальный шарнир SPACER Universal Joint |
1 | |
| 44 | 76769 |
ВИНТ (0.375-16 x 0.880) SCREW (.375-16 x .880) |
3 | |
| 45 | 48461 |
Oil Level Gauge Tube ADAPTER Oil Level Gauge Tube |
1 | disc. |
| 46 | 48462 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.614 x 0.070) O-RING (.614 x .070) |
1 | |
| 47 | 48463 |
ТРУБА Щуп Oil Level Gauge TUBE Dipstick Oil Level Gauge |
1 | disc. |
| 48 | 48464 |
ЩУП Oil Level DIPSTICK Oil Level |
1 | disc. |
| 49 | 35276 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.734 x 0.139) O-RING (.734 x .139) |
1 | |
| 5 | 88031 |
ПЕРЕКЛЮЧАТЕЛЬ В СБОРЕ Oil Temperature SWITCH ASSEMBLY Oil Temperature |
1 | |
| 50 | 48466 |
КРОНШТЕЙН Mounting BRACKET Mounting |
1 | disc. |
| 51 | 34290 |
ВИНТ (0.250-20 x 0.625) SCREW (.250-20 x .625) |
2 | disc. |
| 52 | 26992 |
СТОПОРНАЯ ШАЙБА (0.250), нержавеющая сталь LOCKWASHER (.250) Stainless Steel |
2 | |
| 53 | 47340A1 |
КРОНШТЕЙН В СБОРЕ Transmission Mount - Port BRACKET ASSEMBLY Transmission Mount - Port |
1 | disc. |
| 54 | 35852 |
КРЕПЛЕНИЕ Transmission Bracket MOUNT Transmission Bracket |
1 | disc. |
| 55 | 47334A2 |
КРОНШТЕЙН В СБОРЕ Transmission Mount - Starboard BRACKET ASSEMBLY Transmission Mount - Starboard |
1 | disc. |
| 56 | 35852 |
КРЕПЛЕНИЕ Transmission Bracket MOUNT Transmission Bracket |
1 | disc. |
| 57 | 47462 |
ВИНТ (0.437-14 x 1.250) SCREW (.437-14 x 1.250) |
4 | |
| 58 | 32993 |
СТОПОРНАЯ ШАЙБА (0.437) LOCKWASHER (.437) |
4 | |
| 59 | 47467 |
ВИНТ (0.625-18 x 5.500) SCREW (.625-18 x 5.500) |
2 | |
| 6 | 47483 |
J-ЗАЖИМ J CLIP |
1 | |
| 60 | 47466 |
ШАЙБА (1.125 x 1.750 x 0.16) WASHER (1.125 x 1.750 x .16) |
4 | |
| 61 | 47475 |
ШАЙБА (1.120 x 2.250 x 0.19) WASHER (1.120 x 2.250 x .19) |
2 | |
| 62 | 34846 |
СТОПОРНАЯ ШАЙБА Пружинная шайба (0.636) LOCKWASHER Thackeray Spring (.636) |
2 | |
| 63 | 33171 |
ШАЙБА (0.6406 x 1.750 x 0.125) WASHER (.6406 x 1.750 x .125) |
2 | |
| 64 | 22339 |
ГАЙКА (.625-18) NUT (.625-18) |
2 | superseded |
| 65 | 475166 |
ШЛАНГ В СБОРЕ (30.00") Transmission To Oil Cooler - Design I - Used With Huber Models HOSE ASSEMBLY (30.00 Inches) Transmission To Oil Cooler - Design I - Used With Huber Models |
2 | |
| 65 | 475169 |
ШЛАНГ В СБОРЕ (37.00") Transmission To Oil Cooler - Design II - Used With BAM Models HOSE ASSEMBLY (37.00 Inches) Transmission To Oil Cooler - Design II - Used With BAM Models |
1 | |
| 65 | 4751615 |
ШЛАНГ В СБОРЕ (31.00") Transmission To Oil Cooler - Design II - Used With BAM Models HOSE ASSEMBLY (31.00 Inches) Transmission To Oil Cooler - Design II - Used With BAM Models |
1 | |
| 66 | 60179 |
ВИНТ (0.437-14 x 3.500) SCREW (.437-14 x 3.500) |
6 | |
| 67 | 45176 |
ШАЙБА (0.453 x 0.812 x 0.105), нержавеющая сталь WASHER (.453 x .812 x .105) Stainless Steel |
6 | |
| 68 | 20722 |
ШАЙБА (0.328 x 0.625 x 0.060) WASHER (.328 x .625 x .060) |
1 | disc. |
| 69 | 39107 |
СТОПОРНАЯ ШАЙБА (0.312-24) LOCKWASHER (.312-24) |
1 | |
| 7 | 63186 |
ФИТИНГ (.125-27) To Hose On Bottle FITTING (.125-27) To Hose On Bottle |
1 | disc. |
| 70 | 22053 |
ГАЙКА (0.312-24) NUT (.312-24) |
1 | |
| 71 | 88032A5 |
КАБЕЛЬ В СБОРЕ (3.00"), желто-коричневый/синий CABLE ASSEMBLY (3.00 Inches) Tan/Blue |
1 | |
| 71 | 86322A29 |
КАБЕЛЬ В СБОРЕ (3.00"), черный CABLE ASSEMBLY (3.00 Inches) Black |
1 | |
| 72 | 77054 |
ЛЕНТОЧНЫЙ ХОМУТ (14.50") TIE STRAP (14.50 Inches) |
1 | |
| 73 | 896868A01 |
ЖГУТ ПРОВОДОВ В СБОРЕ Удлинитель - NOTE: This Harness Is Used Between Engine Harness And Connects In Place Of Bravo Shift Plate And The Neutral Switch On The Transmission HARNESS ASSEMBLY Extension - NOTE: This Harness Is Used Between Engine Harness And Connects In Place Of Bravo Shift Plate And The Neutral Switch On The Transmission |
1 | |
| 8 | 846693 |
УПЛОТНЕНИЕ Housing SEAL Housing |
1 | superseded |
| 9 | 47903 |
ПРОКЛАДКА Transmission To Support Housing GASKET Transmission To Support Housing |
1 |
