| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 804908A01 |
КОМПЛЕКТ ПРОКЛАДОК Редуктор GASKET SET Gearcase |
1 | superseded |
| 1 | 898101028 |
КУЛАЧОК Муфта сцепления Component of Complete Gear Housing CAM Clutch Component of Complete Gear Housing |
1 | superseded |
| 10 | 895118002 |
ШАЙБА Component of Complete Gear Housing WASHER Component of Complete Gear Housing |
1 | superseded |
| 11 | 898101172 |
ШТОК ПЕРЕКЛЮЧЕНИЯ ПЕРЕДАЧ SHIFT ROD |
1 | |
| 12 | 16823 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Handle GROMMET Handle |
1 | |
| 13 | 898103026 |
КРОНШТЕЙН BRACKET |
1 | |
| 14 | 82304213 |
БОЛТ Handle BOLT Handle |
1 | superseded |
| 15 | 898101171 |
СТОПОР Рычаг переключения реверса – нержавеющая сталь Handle STOPPER Shift Lever - Stainless Steel Handle |
1 | superseded |
| 16 | 898101112 |
РЫЧАГ Handle LEVER Handle |
1 | |
| 17 | 825702002 |
БОЛТ Нержавеющая сталь BOLT Stainless Steel |
2 | superseded |
| 18 | 898101082 |
ПЛАСТИНА ШЕСТЕРНИ Handle GEAR PLATE Handle |
1 | |
| 19 | 825702002 |
БОЛТ Нержавеющая сталь Handle BOLT Stainless Steel Handle |
6 | superseded |
| 2 | 803760A16 |
КОМПЛЕКТ ШТОКА Эксцентрик – короткий Component of Complete Gear Housing Design II ROD KIT Cam - Short Component of Complete Gear Housing Design II |
1 | disc. |
| 2 | 803760A17 |
КОМПЛЕКТ ШТОКА Эксцентрик – длинный Component of Complete Gear Housing Design II ROD KIT Cam - Long Component of Complete Gear Housing Design II |
1 | disc. |
| 20 | 813028003 |
ПРУЖИНА Handle SPRING Handle |
1 | |
| 21 | 898103T16 |
ВАЛ ПЕРЕКЛЮЧЕНИЯ ПЕРЕДАЧ Handle SHIFT SHAFT Handle |
1 | |
| 22 | 898101135 |
ШТИФТ Handle PIN Handle |
1 | superseded |
| 23 | 8537227 |
ГАЙКА Нейлон Handle NUT Nylon Handle |
1 | |
| 24 | 895106 |
ШАЙБА Нержавеющая сталь Handle WASHER Stainless Steel Handle |
1 | superseded |
| 25 | 895162 |
ВТУЛКА Стальной Handle COLLAR Steel Handle |
1 | superseded |
| 26 | 895160 |
ПЕРЕДАЧА Привод Handle GEAR Drive Handle |
1 | superseded |
| 27 | 895161 |
ПЕРЕДАЧА Ведомый Handle GEAR Driven Handle |
1 | |
| 28 | 898101081 |
ПЛАСТИНА ШЕСТЕРНИ Starboard - Handle GEAR PLATE Starboard - Handle |
1 | |
| 29 | 804892002 |
БАК Дроссельная заслонка Handle DRUM Throttle Handle |
1 | superseded |
| 3 | 16176007 |
ВТУЛКА Component of Complete Gear Housing BUSHING Component of Complete Gear Housing |
1 | |
| 30 | 895118002 |
ШАЙБА Use with 6mm Collar - Handle [0R148895] & Below WASHER Use with 6mm Collar - Handle [0R148895] & Below |
1 | superseded |
| 30 | 953921 |
ШАЙБА Нержавеющая сталь Use with 6.3mm Collar - Handle [0R148896] & Up WASHER Stainless Steel Use with 6.3mm Collar - Handle [0R148896] & Up |
1 | |
| 31 | 898101203 |
ОТКРЫВАТЕЛЬ Дроссельная заслонка Handle OPENER Throttle Handle |
1 | |
| 32 | 895126 |
ВТУЛКА (6 мм) Handle [0R148895] & Below COLLAR (6 mm) Handle [0R148895] & Below |
1 | |
| 32 | 895126004 |
ВТУЛКА Нержавеющая сталь (6.3 мм) Handle [0R148896] & Up COLLAR Stainless Steel (6.3 mm) Handle [0R148896] & Up |
1 | |
| 33 | 82304222 |
БОЛТ Нержавеющая сталь Handle BOLT Stainless Steel Handle |
1 | superseded |
| 34 | 898101166 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Резина Handle GROMMET Rubber Handle |
1 | |
| 35 | 898101110 |
РУЧКА Handle KNOB Handle |
1 | |
| 36 | 898101109 |
СОЕДИНЕНИЕ Handle JOINT Handle |
1 | |
| 37 | 898103018 |
КРОНШТЕЙН Рычаг штока переключения реверса Starboard - Remote Control BRACKET Shift Rod Lever Starboard - Remote Control |
1 | |
| 38 | 825702002 |
БОЛТ Нержавеющая сталь Remote Control BOLT Stainless Steel Remote Control |
2 | superseded |
| 39 | 898103T17 |
ВАЛ ПЕРЕКЛЮЧЕНИЯ ПЕРЕДАЧ Remote Control SHIFT SHAFT Remote Control |
1 | |
| 4 | 898101377 |
СОЕДИНЕНИЕ Шток переключения передач Design II JOINT Shift Rod Design II |
1 | |
| 40 | 898101169 |
РЫЧАГ РЕВЕРСА Remote Control SHIFT ARM Remote Control |
1 | |
| 41 | 823042038 |
БОЛТ Remote Control BOLT Remote Control |
1 | superseded |
| 42 | 161404 |
ШАЙБА Remote Control WASHER Remote Control |
1 | |
| 43 | 803760006 |
ШТОК Кулачок Component of Complete Gear Housing Short - Design I ROD Cam Component of Complete Gear Housing Short - Design I |
1 | disc. |
| 43 | 803760007 |
ШТОК Кулачок Component of Complete Gear Housing Long - Design I ROD Cam Component of Complete Gear Housing Long - Design I |
1 | disc. |
| 44 | 898101173 |
СОЕДИНЕНИЕ Шток переключения передач Design I JOINT Shift Rod Design I |
1 | disc. |
| 5 | 952189 |
ШТИФТ Штифт PIN Dowel |
1 or 2 | |
| 6 | 16179 |
ШТИФТ Component of Complete Gear Housing PIN Component of Complete Gear Housing |
2 | |
| 7 | 161772 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Component of Complete Gear Housing O-RING Component of Complete Gear Housing |
2 | |
| 8 | 161782 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Component of Complete Gear Housing O-RING Component of Complete Gear Housing |
1 | |
| 9 | 82304234 |
БОЛТ Component of Complete Gear Housing BOLT Component of Complete Gear Housing |
1 | superseded |
