| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 898101A45 |
КОМПЛЕКТ КРЕПЕЖА Рулевой механизм ATTACHING KIT Steering |
1 | |
| 1 | 898101195 |
ARM Дроссельная заслонка Handle ARM Throttle Handle |
1 | |
| 10 | 898101205 |
ШТОК Дроссельная заслонка – нержавеющая сталь Handle ROD Throttle - Stainless Steel Handle |
1 | |
| 11 | 898101114 |
СТЕРЖЕНЬ ТЯГИ Дроссельная заслонка Remote Control LINK ROD Throttle Remote Control |
1 | |
| 12 | 16081 |
ГАЙКА Нержавеющая сталь Remote Control NUT Stainless Steel Remote Control |
1 or 2 | |
| 13 | 853745 |
ПРОБКА Remote Control CAP Remote Control |
1 | |
| 14 | 898101004 |
КРОНШТЕЙН Рычаг Shift and Throttle Remote Control BRACKET Arm Shift and Throttle Remote Control |
2 | |
| 15 | 8248324 |
ВИНТ (M6 x 16) Arm Bracket Remote Control SCREW (M6 x 16) Arm Bracket Remote Control |
2 or 4 | |
| 16 | 898101196 |
ARM Дроссельная заслонка Remote Control ARM Throttle Remote Control |
1 | |
| 17 | 898101218 |
ШАЙБА Пластик Remote Control WASHER Plastic Remote Control |
1 or 4 | |
| 18 | 898101174 |
ШПЛИНТ Нержавеющая сталь Remote Control COTTER PIN Stainless Steel Remote Control |
1 or 4 | |
| 19 | 895118002 |
ШАЙБА Remote Control WASHER Remote Control |
1 or 2 | superseded |
| 2 | 823042040 |
БОЛТ Нержавеющая сталь Handle BOLT Stainless Steel Handle |
1 | superseded |
| 20 | 9528624 |
ВТУЛКА (9.3 мм) Remote Control COLLAR (9.3 mm) Remote Control |
1 or 2 | superseded |
| 21 | 823042040 |
БОЛТ Нержавеющая сталь Throttle Arm and Shift Arm Remote Control BOLT Stainless Steel Throttle Arm and Shift Arm Remote Control |
1 or 2 | superseded |
| 22 | 898101113 |
СТЕРЖЕНЬ ТЯГИ Переключение передач Non-Jet/Remote Control LINK ROD Shift Non-Jet/Remote Control |
1 | |
| 23 | 892775 |
СОЕДИНЕНИЕ Кабель Non-Jet/Remote Control JOINT Cable Non-Jet/Remote Control |
1 | |
| 24 | 898101170 |
РЫЧАГ РЕВЕРСА Non-Jet/Remote Control SHIFT ARM Non-Jet/Remote Control |
1 | |
| 25 | 898101087 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Remote Control GROMMET Remote Control |
1 | superseded |
| 26 | 898101189 |
ПЛАСТИНА Remote Control PLATE Remote Control |
1 | disc. |
| 27 | 898101012 |
ВИНТ Remote Control SCREW Remote Control |
2 | superseded |
| 28 | 895141 |
ШАЙБА Нержавеющая сталь Remote Control WASHER Stainless Steel Remote Control |
2 | superseded |
| 29 | 898101231 |
ЗАЖИМ Remote Control CLAMP Remote Control |
1 | |
| 3 | 953921 |
ШАЙБА Нержавеющая сталь Handle WASHER Stainless Steel Handle |
2 | |
| 30 | 8248324 |
ВИНТ (M6 x 16) Remote Control SCREW (M6 x 16) Remote Control |
1 | |
| 31 | 898101045 |
ПРОДОЛЬНАЯ ТЯГА Remote Control DRAG LINK Remote Control |
1 | |
| 32 | 161473 |
ГАЙКА Нейлон Remote Control NUT Nylon Remote Control |
2 | |
| 33 | 9539210 |
ШАЙБА Remote Control WASHER Remote Control |
3 | |
| 34 | 853826001 |
ПРОСТАВКА Remote Control SPACER Remote Control |
1 | |
| 35 | 898101018 |
ВИНТ Remote Control SCREW Remote Control |
1 | |
| 36 | 853825 |
ПРОБКА Remote Control CAP Remote Control |
1 | |
| 37 | 898101256 |
ЗАЖИМ CLAMP |
1 | |
| 4 | 95286029 |
ВТУЛКА (9.5 мм), нержавеющая сталь Handle COLLAR (9.5 mm) Stainless Steel Handle |
1 | |
| 5 | 898101218 |
ШАЙБА Пластик Handle WASHER Plastic Handle |
2 | |
| 6 | 898101174 |
ШПЛИНТ Нержавеющая сталь Handle COTTER PIN Stainless Steel Handle |
2 | |
| 7 | 892775 |
СОЕДИНЕНИЕ Кабель Handle JOINT Cable Handle |
2 | |
| 8 | 16081 |
ГАЙКА Нержавеющая сталь Handle NUT Stainless Steel Handle |
2 | |
| 9 | 898101204 |
ШТОК Дроссельная заслонка Handle ROD Throttle Handle |
1 |
