| # | Part Number | Description | Qty | Status |
|---|
| - |
88397A1 |
SEAL KIT Driveshaft Housing
|
- |
|
| 1 |
861063A4 |
HOUSING ASSEMBLY Driveshaft
|
1 |
|
| 10 |
853635 |
YOKE Gear End (Gray) Meritor Assembly
|
1 |
|
| 10 |
864282T |
YOKE Gear End (Black) GKN Assembly
|
1 |
|
| 11 |
39383T |
SOCKET Center (Gray) Meritor Assembly
|
1 |
superseded
|
| 11 |
865503T |
SOCKET Center (Black) GKN Assembly
|
1 |
|
| 12 |
805536A2 |
CROSS AND BEARING (Gray) Meritor Assembly
|
2 |
|
| 12 |
865493A01 |
CROSS AND BEARING (Black) GKN Assembly
|
2 |
disc.
|
| 13 |
814819A3 |
YOKE Coupler End (Gray) Meritor Assembly
|
1 |
|
| 13 |
865491A01 |
YOKE Coupler End (Black) GKN Assembly
|
1 |
superseded
|
| 14 |
29845 |
O-RING (.924 x .103)
|
2 |
superseded
|
| 14 |
35027 |
O-RING (1.046)
|
1 |
superseded
|
| 15 |
8168111 |
RETAINER
|
1 |
superseded
|
| 16 |
35983 |
RING
|
1 |
|
| 17 |
70937 |
O-RING
|
1 |
superseded
|
| 18 |
66081A2 |
CARRIER ASSEMBLY
|
1 |
superseded
|
| 19 |
823894 |
SEAL Oil
|
1 |
|
| 2 |
79953A2 |
SCREW KIT (.375-16 x .250) Drain
|
1 |
superseded
|
| 20 |
30894A5 |
BEARING KIT Roller
|
1 |
|
| 21 |
853649 |
SPACER Bearing Cup
|
1 |
disc.
|
| 22 |
35980A1 |
SHIM SET
|
AR |
|
| 23 |
853641A2 |
GEAR KIT (20-22 GEARS) (1.47:1 RATIO)
|
1 |
|
| 23 |
853640A2 |
GEAR KIT (24-24 GEARS) (1.62:1 AND 2.00:1 RATIO)
|
1 |
|
| 23 |
853643A2 |
GEAR KIT (17-19 GEARS) (1.81:1 RATIO)
|
1 |
|
| 23 |
853642A2 |
GEAR KIT (20-24 GEARS) (1.94:1 AND 2.40:1 RATIO)
|
1 |
|
| 24 |
35990A1 |
BEARING ASSEMBLY Roller
|
1 |
|
| 24 |
32573A1 |
BEARING ASSEMBLY Roller (1.47:1 RATIO ONLY)
|
1 |
|
| 25 |
45810 |
WASHER
|
1 |
|
| 26 |
22339 |
NUT (.625-18)
|
1 |
superseded
|
| 27 |
36178A1 |
SHIM SET
|
AR |
superseded
|
| 3 |
19183 |
WASHER Fiber
|
1 |
superseded
|
| 4 |
17997A1 |
SPRING KIT
|
1 |
|
| 5 |
66302 |
SEAL Oil [0M400410] & Below
|
2 |
superseded
|
| 5 |
864319 |
SEAL Oil [0M400412] & Up
|
1 |
|
| 6 |
821564 |
PLUG [0W847948] & Below
|
1 |
superseded
|
| 6 |
866511 |
PLUG [0W847949] & Up
|
1 |
|
| 7 |
814386 |
WEAR PAD (PORT)
|
1 |
superseded
|
| 7 |
814387 |
WEAR PAD (STARBOARD)
|
1 |
superseded
|
| 8 |
824928 |
PLUG Rubber
|
1 |
superseded
|
| 9 |
814819A7 |
UNIVERSAL JOINT (Gray) Meritor Assembly
|
1 |
superseded
|
| 9 |
864281A2 |
UNIVERSAL JOINT (Black) GKN Assembly
|
1 |
|
