| # | Part Number | Description | Qty | Status |
|---|
| 1 |
864592T1 |
HOUSING Thermostat
|
1 |
|
| 10 |
530451 |
GASKET Lower Thermostat Housing
|
1 |
|
| 11 |
98508 |
SCREW (.375-16 x 3.00)
|
2 |
superseded
|
| 12 |
34714 |
WASHER
|
2 |
|
| 13 |
98477A2 |
VALVE ASSEMBLY
|
1 |
|
| 14 |
98475 |
BALL Nylon Check
|
2 |
|
| 15 |
75533 |
SPRING
|
2 |
|
| 16 |
89302 |
WASHER (.203 x .406 x .040)
|
2 |
|
| 17 |
98476 |
SCREW (#10-32 x 6.00)
|
1 |
|
| 18 |
826709106 |
NUT (#10-32) Stainless Steel
|
1 |
superseded
|
| 2 |
32803 |
PLUG Pipe (.375-18) Brass
|
1 |
superseded
|
| 3 |
806490T |
SENDER Water Temperature
|
1 |
|
| 4 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
1 |
|
| 5 |
68219 |
NUT (#10-32) Stainless Steel
|
1 |
|
| 6 |
805218T |
SENSOR
|
1 |
|
| 7 |
806871 |
GASKET Thermostat Housing
|
1 |
superseded
|
| 8 |
807252T1 |
THERMOSTAT 60 Degree C (140 Degree F)
|
1 |
superseded
|
| 9 |
806922 |
SLEEVE Thermostat
|
1 |
superseded
|
