| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0085932 |
LONGBLOCK ASSEMBLY
|
1 |
disc.
|
| 1 |
881126K01 |
FILTER Oil
|
1 |
|
| 10 |
8161631 |
THERMOSTAT
|
1 |
superseded
|
| 11 |
849983 |
PISTON Oil Thermostat
|
1 |
superseded
|
| 12 |
816162 |
SPRING
|
1 |
|
| 13 |
864701 |
O-RING (1.112 x .103)
|
1 |
|
| 14 |
8161651 |
COVER Oil Thermostat
|
1 |
superseded
|
| 15 |
848571 |
RING Retaining
|
1 |
|
| 16 |
32561 |
PLUG Pipe - Allen Head (.250-18)
|
1 |
superseded
|
| 17 |
8M0007770 |
HOSE ASSEMBLY Oil (35.50 Inches) Filter Base To Filter
|
1 |
|
| 18 |
8M0007771 |
HOSE ASSEMBLY Oil (39.26 Inches) Filter To Base
|
1 |
|
| 19 |
42077 |
SEAL
|
1 |
|
| 2 |
805632 |
CONNECTOR Oil Fitler Base
|
1 |
|
| 20 |
8M0007144 |
FITTING Oil Filter Base
|
1 |
|
| 21 |
48872 |
FITTING 45 Degree Elbow
|
2 |
|
| 22 |
8M0024516 |
HOSE ASSEMBLY Oil (29.25 Inches) Cooler To Filter Base
|
1 |
|
| 23 |
48872 |
FITTING 45 Degree Elbow
|
1 |
|
| 24 |
879330T34 |
COOLER ASSEMBLY Oil
|
1 |
|
| 25 |
8M0036570 |
GASKET
|
2 |
|
| 26 |
39349 |
SCREW (.312-18 x .750) Stainless Steel
|
2 |
|
| 27 |
48872 |
FITTING 45 Degree Elbow
|
1 |
|
| 3 |
807211 |
VALVE Relief Oil By Pass - 30 PSI
|
1 |
|
| 4 |
8M0021768 |
BASE Oil Filter
|
1 |
|
| 5 |
891953 |
PLUG (18 mm)
|
1 |
|
| 6 |
805632 |
CONNECTOR Oil Filter
|
1 |
|
| 7 |
841870 |
CONNECTOR Oil Thermostat Housing
|
1 |
|
| 8 |
32507 |
O-RING (3.359 x .139)
|
1 |
|
| 9 |
849885T2 |
HOUSING Oil Thermostat
|
1 |
|
| NS |
849885A04 |
HOUSING ASSEMBLY Oil Thermostat
|
1 |
|
