| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0085932 |
LONGBLOCK ASSEMBLY
|
1 |
disc.
|
| 1 |
809995 |
COVER Rocker With Oil Fill Hole
|
1 |
|
| 1 |
809996 |
COVER Rocker Without Oil Fill Hole
|
1 |
disc.
|
| 10 |
815504105 |
CLAMP Worm Gear (11-18 mm) Hose
|
2 |
superseded
|
| 11 |
807688T |
TUBE Oil Fill
|
1 |
|
| 12 |
NSS |
NOT SOLD SEPARATE Push Rod
|
16 |
|
| 13 |
NSS |
NOT SOLD SEPARATE Exhaust Valve, Standard
|
8 |
|
| 13 |
NSS |
NOT SOLD SEPARATE Exhaust Valve, .030 Oversize
|
AR |
|
| 14 |
NSS |
NOT SOLD SEPARATE Intake Valve
|
8 |
|
| 15 |
NSS |
NOT SOLD SEPARATE Intake Seal
|
8 |
|
| 15 |
NSS |
NOT SOLD SEPARATE Exhaust Seal
|
8 |
|
| 16 |
NSS |
NOT SOLD SEPARATE Spring
|
16 |
|
| 17 |
NSS |
NOT SOLD SEPARATE Cap
|
16 |
|
| 18 |
NSS |
NOT SOLD SEPARATE Key
|
32 |
|
| 19 |
NSS |
NOT SOLD SEPARATE Rock Arm Kit W/ Push Rods
|
1 |
|
| 2 |
18710002 |
CAP
|
1 |
|
| 20 |
NSS |
NOT SOLD SEPARATE Ball Unit
|
16 |
|
| 21 |
NSS |
NOT SOLD SEPARATE Nut
|
16 |
|
| 22 |
8M0115140 |
CYLINDER HEAD ASSEMBLY Complete
|
2 |
disc.
|
| 23 |
NSS |
NOT SOLD SEPARATE Stud, .003 Oversized
|
AR |
|
| 24 |
NSS |
NOT SOLD SEPARATE Gasket
|
2 |
|
| 25 |
NSS |
NOT SOLD SEPARATE Screw
|
16 |
|
| 26 |
NSS |
NOT SOLD SEPARATE Screw
|
4 |
|
| 27 |
NSS |
NOT SOLD SEPARATE Screw
|
14 |
|
| 28 |
878187 |
SENSOR ASSEMBLY Knock
|
1 |
superseded
|
| 29 |
82670912 |
NUT (.375-16) Stainless Steel
|
11 |
|
| 3 |
8M0084557 |
SCREW
|
8 |
|
| 30 |
863414 |
STUD Knock Sensor
|
1 |
|
| 31 |
865982007 |
SCREW (.375-16 x 1.25) Hex Flange
|
2 |
|
| 4 |
17467 |
GASKET Rocker Cover
|
2 |
superseded
|
| 5 |
8M0071559 |
BUSHING
|
2 |
|
| 6 |
97850T |
ELBOW 90 Degree
|
1 |
|
| 7 |
8M0062321 |
HOSE (33.00 Inches Bulk)
|
1 |
|
| 8 |
8M2017060 |
VALVE PCV
|
1 |
|
| 9 |
1589424 |
HOSE (16.50 Inches Bulk) Breather
|
1 |
superseded
|
