| # | Part Number | Description | Qty | Status |
|---|
| 1 |
862031T1 |
ALTERNATOR ASSEMBLY 70 Amp With 62mm Pulley (Non Serviceable)
|
1 |
|
| 10 |
863443T1 |
BRACKET
|
1 |
|
| 11 |
862083T |
BRACKET Idler Adjusting
|
1 |
|
| 12 |
865193 |
BUSHING
|
1 |
|
| 13 |
859135 |
NUT (.437-20) Brass/Nickel Plated
|
1 |
|
| 14 |
8183812 |
PINION STUD (.437-20) Stainless Steel
|
1 |
superseded
|
| 15 |
864625T |
PULLEY (4.25 Inch Diameter)
|
1 |
|
| 16 |
34353 |
SCREW (.375-16 x 1.00)
|
2 |
|
| 17 |
862082T |
BRACE Power Steering
|
1 |
|
| 18 |
40001188 |
SCREW (M10 x 20)
|
1 |
disc.
|
| 19 |
864456T |
BRACKET Alternator Brace
|
1 |
|
| 2 |
400212 |
NUT (M6) Stainless Steel
|
2 |
|
| 20 |
34353 |
SCREW (.375-16 x 1.00)
|
1 |
|
| 21 |
862085T |
BRACE Idler Bracket
|
1 |
|
| 22 |
8M6500024 |
PULLEY
|
1 |
|
| 23 |
865193 |
BUSHING
|
1 |
|
| 24 |
56393 |
SCREW (.437-20 x 1.75)
|
1 |
|
| 25 |
859135 |
NUT (.437-20) Brass/Nickel Plated
|
1 |
|
| 26 |
862778 |
BRACKET Alternator Brace
|
1 |
|
| 27 |
34353 |
SCREW (.375-16 x 1.00)
|
1 |
|
| 28 |
865615Q03 |
BELT Serpentine
|
1 |
|
| 3 |
40001134 |
SCREW (M8 x 25)
|
1 |
|
| 4 |
828213 |
SCREW (.312-18 x 1.500) Hex Flange
|
2 |
|
| 5 |
57792 |
WASHER
|
2 |
|
| 6 |
26484 |
NUT (.312-18)
|
2 |
superseded
|
| 7 |
863211T01 |
BRACKET
|
1 |
|
| 8 |
98261 |
SCREW (.375-16 x .750)
|
2 |
|
| 9 |
20084 |
WASHER (.328 x .562 x .062)
|
1 |
|
| NS |
8M0086198 |
BRACKET Oil Filter
|
1 |
disc.
|
