| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 806871A96 |
КОМПЛЕКТ ПРОКЛАДОК Капитальный ремонт CONTENTS INDICATED BY FOOTNOTE 16. GASKET SET Overhaul CONTENTS INDICATED BY FOOTNOTE 16. |
1 | |
| 1 | 17619 |
КОЛЛЕКТОР Впуск MANIFOLD Intake |
1 | disc. |
| 10 | 807729T |
ШКИВ Water Pump PULLEY Water Pump |
1 | superseded |
| 11 | 47277 |
ВИНТ (0.312-24 x 0.750) SCREW (.312-24 x .750) |
4 | |
| 12 | 809892 |
БАЛАНСИР Виброгаситель BALANCER Harmonic |
1 | superseded |
| 13 | 807730T |
ШКИВ Crankshaft PULLEY Crankshaft |
1 | |
| 14 | 8077554 |
РЕМЕНЬ Поликлиновый BELT Serpentine |
1 | superseded |
| 15 | 32515 |
ВИНТ (0.437-20 x 2.50) SCREW (.437-20 x 2.50) |
1 | superseded |
| 16 | 39131 |
СТОПОРНАЯ ШАЙБА (0.437) LOCKWASHER (.437) |
1 | |
| 17 | 35332 |
ШАЙБА WASHER |
1 | superseded |
| 18 | 34352 |
ВИНТ (0.375-24 x 0.875) SCREW (.375-24 x .875) |
3 | |
| 19 | 34714 |
ШАЙБА WASHER |
3 | |
| 2 | 11976 |
ВИНТ (0.375-16 x 1.00) SCREW (.375-16 x 1.00) |
9 | |
| 2 | 852939 |
БОЛТ (3/8-16 x 1.5") BOLT (3/8-16 x 1.5 In.) |
3 | disc. |
| 20 | 835005 |
КРЫШКА В СБОРЕ Распределение (SCREWS-GROMMETS-OIL SEAL AND GASKET ARE NOT SOLD SEPARATELY.) TIMING COVER ASSEMBLY Without Crank Position Portal (SCREWS-GROMMETS-OIL SEAL AND GASKET ARE NOT SOLD SEPARATELY.) |
1 | |
| 21 | 53338 |
КЛАПАН В СБОРЕ Фильтр VALVE ASSEMBLY Filter |
1 | superseded |
| 22 | 54786 |
ВИНТ (0.312-18 x 1.250) SCREW (.312-18 x 1.250) |
2 | |
| 23 | 14957 |
ФИЛЬТР Масло FILTER Oil |
1 | superseded |
| 24 | 852940 |
КОРПУС В СБОРЕ Со шпильками Oil Seal (REAR) HOUSING ASSEMBLY With Studs Oil Seal (REAR) |
1 | |
| 25 | 14241 |
ПРОКЛАДКА GASKET |
1 | superseded |
| 26 | 852941 |
УПЛОТНЕНИЕ Oil (REAR) SEAL Oil (REAR) |
1 | |
| 27 | 14243 |
БОЛТ (0.250-20 x 1.750) BOLT (.250-20 x 1.750) |
1 | superseded |
| 28 | 14242 |
БОЛТ (0.250-20 x 0.875) BOLT (.250-20 x .875) |
2 | |
| 29 | 14263 |
ШТИФТ Штифт PIN Dowel |
1 | |
| 3 | 48358 |
ПРОБКА (0.375) PLUG (.375) |
1 | superseded |
| 30 | 816730 |
ГАЙКА (0.250-20) NUT (.250-20) |
1 | superseded |
| 31 | 14827 |
ШПИЛЬКА (0.250-20 x 2.180) STUD (.250-20 x 2.180) |
1 | |
| 4 | NSS |
НЕ ПРОДАЕТСЯ ОТДЕЛЬНО STUD (GM#10229247) NOT SOLD SEPARATE STUD (GM#10229247) |
4 | |
| 5 | 72647 |
ПРЕДОХРАНИТЕЛЬ GUARD |
1 | disc. |
| 6 | 17145 |
КОМПЛЕКТ ПРОКЛАДОК Intake Manifold (Use RTV Silicone Sealant for end gasket - See Service Manual) GASKET SET Intake Manifold (Use RTV Silicone Sealant for end gasket - See Service Manual) |
1 | |
| 7 | 850399 |
НАСОС В СБОРЕ Вода PUMP ASSEMBLY Water |
1 | superseded |
| 8 | 34897 |
ПРОКЛАДКА Water Pump GASKET Water Pump |
2 | |
| 9 | 32132 |
ВИНТ (0.375-16 x 1.750) SCREW (.375-16 x 1.750) |
1 | |
| 9 | 47688 |
ВИНТ (0.375-16 x 2.750) SCREW (.375-16 x 2.750) |
1 | |
| 9 | 35342 |
ШПИЛЬКА (0.312-24/0.375-16 x 2.5625) STUD (.312-24/.375-16 x 2.5625) |
2 | superseded |
