| # | Part Number | Description | Qty | Status |
|---|
| - |
850396A1 |
GASKET/SEAL SET Powerhead
|
1 |
|
| - |
9763A64 |
POWERHEAD ASSEMBLY Complete With Reed Blocks
|
1 |
superseded
|
| - |
9763T66 |
POWERHEAD ASSEMBLY Complete Without Reed Blocks
|
1 |
disc.
|
| 1 |
834976 |
ATTENUATOR Sound
|
1 |
|
| 10 |
18178 |
ROLLER
|
1 |
|
| 11 |
15124 |
SCREW (#10-32 x .750)
|
3 |
|
| 12 |
89302 |
WASHER (.203 x .406 x .040)
|
3 |
|
| 13 |
69432 |
LOCKWASHER External (#10)
|
3 |
|
| 14 |
85557732 |
DECAL EPA Label Information On The Side Of The Sound Attenuator [0E288000] THRU [0E344999]
|
1 |
superseded
|
| 14 |
85698525 |
DECAL EPA Label Information On The Side Of The Sound Attenuator [0E345000] THRU [0E369299]
|
1 |
superseded
|
| 2 |
892211 |
GASKET Attenuator To Carburetor
|
3 |
|
| 3 |
884891 |
SCREW (.250-28 x 2.500) With Nylon Patch - Stainless Steel
|
6 |
|
| 4 |
69057 |
WASHER (.281 x .734 x .063)
|
6 |
|
| 5 |
815784 |
CAP
|
3 |
|
| 6 |
828277A1 |
LINKAGE KIT Throttle
|
1 |
disc.
|
| 7 |
8M0203923 |
THROTTLE LEVER
|
1 |
|
| 8 |
8M0203922 |
THROTTLE LEVER
|
1 |
|
| 9 |
NSS |
NOT SOLD SEPARATE Throttle Link
|
1 |
|
