| # | Part Number | Description | Qty | Status |
|---|
| - |
809939A1 |
SEAL/GASKET SET Jet Drive Housing (See Seal/Gasket Set - Jet Drive Housing Section For Parts Breakdown)
|
1 |
|
| - |
804852A1 |
GASKET/SEAL SET Powerhead (See Gasket/Seal Set - Powerhead Section For Parts Breakdown)
|
1 |
|
| - |
858257T11 |
POWERHEAD ASSEMBLY (Complete With Reed Blocks)
|
1 |
superseded
|
| - |
858257T25 |
POWERHEAD ASSEMBLY (Complete Without Reed Blocks)
|
1 |
disc.
|
| 1 |
820543A3 |
ADAPTER ASSEMBLY Flushing
|
1 |
|
| 10 |
850257 |
FITTING (90 Degree)
|
1 |
disc.
|
| 11 |
826356 |
SCREW AND WASHER (.312-18 x 1.500)
|
2 |
superseded
|
| 12 |
55098 |
J CLIP
|
1 |
superseded
|
| 13 |
73286 |
SCREW (.250-20 x .500) Stainless Steel
|
1 |
|
| 14 |
847526 |
WASHER
|
18 |
disc.
|
| 15 |
55300 |
SCREW (.312-18 x 5.250)
|
18 |
|
| 16 |
850390 |
DECAL (Flushing Adapter)
|
1 |
|
| 17 |
89766 |
SCREW (#10-32 x .620) Stainless Steel
|
2 |
|
| 18 |
850160 |
CLIP Flushing Assembly Holder
|
1 |
disc.
|
| 19 |
830881 |
COVER Exhaust Manifold
|
1 |
superseded
|
| 2 |
821908 |
PLUG Top
|
1 |
|
| 20 |
855874 |
GASKET Exhaust Manifold Cover
|
1 |
superseded
|
| 21 |
858893T |
MANIFOLD Exhaust
|
1 |
|
| 22 |
190507 |
GASKET Exhaust Manifold
|
1 |
superseded
|
| 23 |
814754 |
SEAL (12.50 Inches) Exhaust Manifold (12.500 Inches)
|
1 |
|
| 24 |
830242 |
GASKET (Adaptor To Block)
|
1 |
superseded
|
| 25 |
830747 |
HOSE ASSEMBLY Water Inlet
|
1 |
disc.
|
| 26 |
8204521 |
FITTING Water Inlet Hose
|
1 |
disc.
|
| 27 |
830126 |
ADAPTER (Engine To Pump)
|
1 |
|
| 28 |
37828 |
WASHER (.390 x .625 x .062) Stainless Steel
|
12 |
|
| 29 |
35787 |
SCREW (.375-16 x 2.250)
|
4 |
|
| 3 |
821915 |
WASHER
|
1 |
|
| 30 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
2 |
|
| 31 |
48424 |
SCREW (.375-16 x 1.620)
|
8 |
|
| 32 |
920071 |
FITTING (90 Degree) (.250-18)
|
1 |
|
| 33 |
629101 |
FITTING Elbow - 90 Degree (.125-27) (.125-27)
|
1 |
|
| 34 |
816311T |
TIE STRAP (8.00 Inches)
|
3 |
|
| 35 |
1678978 |
HOSE (9.00 Feet Bulk) Siphon (Cut 42.00 Inches)
|
1 |
superseded
|
| 36 |
826702 |
SIPHON BREAK
|
1 |
superseded
|
| 37 |
1678978 |
HOSE (9.00 Feet Bulk) Siphon (Cut 18.00 Inches)
|
1 |
superseded
|
| 38 |
415825 |
CLAMP Nylon (Used On Design I)
|
1 |
|
| 38 |
816311T |
TIE STRAP (8.00 Inches) (Used On Design II)
|
1 |
|
| 39 |
826703 |
FILTER Siphon Hose (Design I - Brass/Copper)
|
1 |
superseded
|
| 39 |
8348084 |
STRAINER Siphon Hose (Design II - Nylon)
|
1 |
|
| 4 |
30641 |
O-RING (.299 x .103)
|
1 |
|
| 5 |
821963 |
CHECK VALVE
|
1 |
superseded
|
| 6 |
33066 |
CONNECTOR (.500-14) Straight - Brass
|
1 |
|
| 7 |
815504206 |
CLAMP Worm Gear
|
1 |
|
| 8 |
47642 |
HOSE (49.00 Inches Bulk) (Cut 23.500 Inches)
|
1 |
|
| 9 |
815504206 |
CLAMP Worm Gear
|
1 |
|
