| # | Part Number | Description | Qty | Status |
|---|
| 1 |
863744T2 |
TRANSMISSION (1.5:1 Ratio) (630A) Down Angle Mechanical Shift
|
1 |
disc.
|
| 1 |
863744T3 |
TRANSMISSION (2.0:1 Ratio) (630A) Down Angle Mechanical Shift
|
1 |
superseded
|
| 1 |
863744T4 |
TRANSMISSION (2.50:1 Ratio) (630A) Down Angle Mechanical Shift
|
1 |
superseded
|
| 1 |
863744T5 |
TRANSMISSION (2.70:1 Ratio) (630A) Down Angle Mechanical Shift
|
1 |
|
| 1 |
NLA |
No Longer Available (800A) Down Angle Mechanical Shift
|
1 |
|
| 1 |
863745T2 |
TRANSMISSION (1.5:1 Ratio) (630V) V-Drive Mechanical Shift
|
1 |
disc.
|
| 1 |
863745T3 |
TRANSMISSION (2.0:1 Ratio) (630V) V-Drive Mechanical Shift
|
1 |
disc.
|
| 1 |
863745T4 |
TRANSMISSION (2.5:1 Ratio) (630V) V-Drive Mechanical Shift
|
1 |
disc.
|
| 1 |
896346701 |
TRANSMISSION (1.5:1 Ratio) Complete Assy. Down Angle Transmission
|
1 |
disc.
|
| 1 |
896346702 |
TRANSMISSION (2.0:1 Ratio) Complete Assy. Down Angle Transmission
|
1 |
disc.
|
| 1 |
896346703 |
TRANSMISSION (2.5:1 Ratio) Complete Assy. Down Angle Transmission
|
1 |
disc.
|
| 1 |
896346707 |
TRANSMISSION (1.5:1 Ratio) Complete Assy. V Drive Transmission
|
1 |
disc.
|
| 1 |
896346708 |
TRANSMISSION (2.0:1 Ratio) Complete Assy. V Drive Transmission
|
1 |
disc.
|
| 1 |
896346709 |
TRANSMISSION (2.5:1 Ratio) Complete Assy. V Drive Transmission
|
1 |
disc.
|
| 1 |
863744R03 |
TRANSMISSION ASSEMBLY Remanufactured (2.0:1 Ratio) Down Angle Transmission
|
1 |
disc.
|
| 1 |
863744R04 |
TRANSMISSION ASSEMBLY Remanufactured (2.5:1 Ratio) Down Angle Transmission
|
1 |
|
| 1 |
863744R05 |
TRANSMISSION ASSEMBLY Remanufactured (2.7:1 Ratio) Down Angle Transmission
|
1 |
disc.
|
| 1 |
863745R02 |
TRANSMISSION Remanufactured (1.5:1 Ratio) V Drive Transmission
|
1 |
disc.
|
| 1 |
863745R03 |
TRANSMISSION Remanufactured (2.0:1 Ratio) V Drive Transmission
|
1 |
disc.
|
| 1 |
863745R04 |
TRANSMISSION Remanufactured (2.5:1 Ratio) V Drive Transmission
|
1 |
disc.
|
| 10 |
32993 |
LOCKWASHER (.437)
|
4 |
|
| 11 |
22024 |
NUT (.437-14)
|
4 |
|
| 12 |
88031 |
SWITCH ASSEMBLY
|
1 |
|
| 13 |
8054781 |
HOSE (19.50)
|
2 |
|
| 14 |
806238 |
BRACKET
|
1 |
|
| 15 |
40001124 |
SCREW (M8 x 14)
|
2 |
|
| 16 |
400247 |
LOCKWASHER (M8)
|
2 |
|
| 17 |
97477A3 |
STUD KIT
|
2 |
|
| 18 |
863832T01 |
COOLER Transmission Oil
|
1 |
|
| 19 |
805546A2 |
BRACKET Oil Cooler
|
1 |
|
| 2 |
805259 |
STUD
|
4 |
|
| 2 |
8M0034453 |
STUD (7/16 x 2.19) (Hurth 800A Only)
|
4 |
|
| 20 |
772233 |
PAD
|
1 |
|
| 21 |
815504232 |
CLAMP Worm Gear (2.50 Diameter)
|
1 |
|
| 22 |
34353 |
SCREW (.375-16 x 1.00)
|
1 |
|
| 23 |
35048 |
LOCKWASHER (.375)
|
1 |
|
| 24 |
813300 |
SWITCH Neutral Safety
|
1 |
|
| 25 |
8M6000623 |
SENSOR Water Pressure 50 PSI
|
1 |
superseded
|
| 26 |
879194241 |
FILTER KIT Oil
|
1 |
|
| 27 |
813407 |
O-RING
|
1 |
|
| 28 |
NLA |
No Longer Available O-Ring
|
1 |
|
| 3 |
22248 |
WASHER (.453 x .875 x .060)
|
4 |
|
| 3 |
79552 |
WASHER (.453 x .750 x .062) Stainless Steel (Hurth 800A Only)
|
4 |
|
| 4 |
34933 |
NUT (.437-20) Stainless Steel
|
4 |
superseded
|
| 4 |
859116 |
NUT (.437-20) (Hurth 800A Only)
|
1 |
|
| 5 |
47462 |
SCREW (.437-14 x 1.250)
|
2 |
|
| 6 |
32993 |
LOCKWASHER (.437)
|
2 |
|
| 7 |
79476A1 |
FLANGE ASSEMBLY (5.00 x 1.00)
|
OPT |
disc.
|
| 7 |
79476A3 |
FLANGE ASSEMBLY (5.00 x 1.25)
|
OPT |
disc.
|
| 7 |
79476A4 |
FLANGE ASSEMBLY (5.00 x 1.375)
|
OPT |
|
| 7 |
79476A5 |
FLANGE ASSEMBLY (5.00 x 1.50)
|
OPT |
|
| 7 |
79476A6 |
FLANGE ASSEMBLY (5.00 x 1.75)
|
OPT |
|
| 8 |
60171 |
SCREW (.375-16 x 1.250)
|
2 |
|
| 8 |
60169 |
SCREW (.375-16 x .750)
|
2 |
|
| 9 |
805159 |
SCREW (.437-20 x 1.500)
|
4 |
|
