| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0131208 |
COMM CAP ASSEMBLY FW, With Seals and Bushing Use With 40 and Greater Thrust Motors
|
1 |
disc.
|
| 1 |
8M0105535 |
HEAD AND HANDLE ASSEMBLY Freshwater (Black) 1 Inch Column
|
1 |
disc.
|
| 1 |
8M0105541 |
HEAD AND HANDLE ASSEMBLY Freshwater (Black) 1.25 Inch Column
|
1 |
|
| 10 |
8M0105503 |
HARDWARE KIT, PROPELLER
|
1 |
disc.
|
| 11 |
NSS |
NOT SOLD SEPARATE WASHER
|
1 |
|
| 12 |
MBR10202T |
PIN Prop Drive (.156 x 1.00)
|
1 |
|
| 13 |
8M4002567 |
MOUNT ASSEMBLY Complete, 09 Transom
|
1 |
superseded
|
| 14 |
8M0059805 |
MOUNT ASSEMBLY Complete, 03 Transom
|
1 |
disc.
|
| 15 |
8M0058715 |
CABLE ASSEMBLY
|
1 |
disc.
|
| 16 |
8M0058717 |
CABLE ASSEMBLY
|
1 |
disc.
|
| 17 |
8M0119628 |
HYSOL EPOXY ADHESIVE 50ml
|
1 |
|
| 2 |
8M0105534 |
HEAD ASSEMBLY Freshwater (Black) 1 Inch Column
|
1 |
disc.
|
| 2 |
8M0105540 |
HEAD ASSEMBLY Freshwater (Black) 1.25 Inch Column
|
1 |
|
| 3 |
8M0105538 |
HANDLE ASSEMBLY
|
1 |
|
| 4 |
8M4002637 |
SWITCH 5 Speed
|
1 |
superseded
|
| 5 |
NSS |
NOT SOLD SEPARATE SCREW
|
2 |
|
| 6 |
8M0058718 |
COLLAR, Depth 1.00 Inch
|
1 |
|
| 6 |
8M4002640 |
COLLAR, Depth 1.25 inch
|
1 |
disc.
|
| 7 |
NSS |
NOT SOLD SEPARATE COLUMN 30 INCH Aluminum
|
1 |
|
| 7 |
NSS |
NOT SOLD SEPARATE COLUMN 36 IINCH Aluminum
|
1 |
|
| 7 |
8M0096829 |
COLUMN 36 INCH, Composite
|
1 |
disc.
|
| 8 |
NSS |
NOT SOLD SEPARATE MOTOR
|
1 |
|
| 9 |
MGA0476B |
PROPELLER KIT 2 blade, 3 inch 30 lb. Models
|
1 |
|
| 9 |
8M4002641 |
PROPELLER KIT 3 Blade with Wrench 40, 45, 55 lb. Models
|
1 |
|
